BEFORE YOU BEGIN

LOCATION OF THE UNIT
Place the equipment on a level and stable surface away from direct sunlight.
The intense UV light can cause discoloration on the plastics. Locate your
equipment in an area with cool temperatures and low humidity. Please
leave a clear zone on both sides of the equipment that is at least 24"
(600 mm). This zone must be clear of any obstruction and provide the
user a clear exit path from the machine. Do not place the equipment in
any area that will block any vent or air openings. The equipment should
not be located in a garage, covered patio, near water or outdoors.
LEVELING THE EQUIPMENT
The equipment should be level for optimum use. Once you have
placed the equipment where you intend to use it, raise or lower one
or both of the adjustable levelers located on the bottom of the frame.
Use 6mm hex key through the access hole (shown below).
A carpenter's level is recommended.
NOTE: There are only two levelers on the equipment.
WARNING!
Our equipment is heavy, use care and additional help if necessary when
moving. Failure to follow these instructions could result in injury.
FREE AREA
0.6 0.6
m
(2 ) (2
ft ft
18
All manuals and user guides at all-guides.com
0.6
m m
) (2 )
ft
POWER
If the equipment is powered by a power supply, the power must be plugged
into the power jack, which is located in the front of the equipment near the
stabilizer tube. Some equipment has a power switch, located next to the power
jack. Make sure it is in the ON position. Unplug cord when not in use.
WARNING!
Never operate equipment if it has a damaged cord or plug, if it is not working properly, if it has been
damaged, or immersed in water. Contact Customer Tech Support for examination and repair.
RECUMBENT SEAT HEIGHT
To adjust the seat height on the Recumbent Cycle, locate the orange lever under the seat
before you mount the Cycle. Place your right hand on the orange adjustment handle
under the seat. Place feet on the ground while seated and slide forward if needed. Place
feet on pedals, gently lift lever under the seat. Using legs, slowly push and slide the seat
up or down to desired position. Release lever and allow to lock into place.
UPRIGHT SEAT HEIGHT
To raise or lower the seat height on the upright cycle, locate the orange pull pin at the
base of the seat post. Pull the pin out and set the seat to the desired height. Release the
pin to lock.
The seat height adjusts from level 1 to 23. Do not raise the seat past level 23.
