Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Date Code Position (Fig. A)
The date code
 28
, which also includes the year of manufacture,
is printed into the housing.
Example:
2018 XX XX
Year of Manufacture
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury could result.
On/off switch
1
Grinding wheel
2
Workpiece support
3
Bracket
4
Honing wheel
5
Spark guard
6
Intended Use
Your D
WALT tool grinding and honing machine was developed
e
for sharpening and honing knives, chisels and other cutting
tools. The machine is never to be used for grinding magnesium
tools. The machine is intended for intermittent use only.
DO nOt use under wet conditions or in the presence of
flammable liquids or gases.
The grinding and honing machine is a professional power tool.
DO nOt let children come into contact with the tool.
Supervision is required when inexperienced operators use
this tool.
Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can cause injury.
Unpacking the Machine and its Parts
1. Carefully lift the machine out of its package.
All manuals and user guides at all-guides.com
2. Take out the accessories and hardware parts.
Required and Recommended Tools
Apart from the tools included with the machine, the following
tools are required:
-
Torque wrench
Mounting the Machine to the Workbench
(Fig. B)
The machine must be mounted onto the workbench.
1. Mark the position of the four mounting holes provided in
the base of the machine on the workbench.
2. Drill a Ø 6.5 mm hole at each of the marked positions.
3. Place the machine on the workbench and insert an M6 bolt
with a washer through the mounting holes in the base into
each of the holes drilled in the workbench. Make sure the
protruding length X (see Figure) is at least 15 mm for each
of the bolts used.
4. Place a nut on each of the bolts and securely tighten the
nuts (torque: 8 Nm).
Changing the Grinding Wheel (Fig. C, D)
1. Remove the three nuts
 7
2. Remove the guard cover
 8
3. Remove the nut
from the spindle
 9
supplied. The nut on the right spindle has a right thread
(Fig. C), the nut on the left spindle a left thread (Fig. D).
4. Take the outer flange
 11
, the packing piece
wheel
 13
from the spindle.
5. Place the new wheel onto the spindle.
6. Replace the packing piece, the outer flange and the nut on
the spindle.
7. Securely tighten the nut
 9
8. Replace the guard cover.
9. Replace the three nuts
 7
and securely tighten them
(torque: 5 Nm).
10. Switch on the machine and let the wheel run with no load
for one minute to check for cracks.

WARNING: Do not use a damaged wheel.
Mounting the spark guard (Fig. E, F)
The spark guard offers additional protection from sparks and
should be used whenever possible. A spark guard is supplied for
each wheel.
1. Fit the transparent screen
 14
inserting a mushroom head bolt
guard and placing a washer
(Fig. E). Tighten the nut.
2. Hold the spark guard against the edge on top of the wheel
case
 18
as shown (Fig. F).
3. Insert a mushroom head bolt
wheel case.
4. Place a washer
 20
and nut
the nut hand-tight.
EngLIsh
using the spanner supplied.
.
using the spanner
 10
 12
and the
(torque: 6 Nm).
to the spark guard
 6
by
into the screen and the
 15
and nut
onto the bolt
 16
 17
into the guard and the
 19
 21
onto the bolt and tighten
