Mounting and Operation

The following table indicates the action objectives for mounting and operation of the power tool. The instructions for each action
objective are shown aside. Depending on the type of application, various instruction combinations are required. Observe the
safety instructions.
Action
Removing the battery
Inserting the battery
Mounting application tools
Reversing the rotational direction
Setting the torque
Setting the torque (only when using GWA FC2
angle drill head)
Selecting the drilling position
Mounting the keyless chuck (GFA FC2) or off-set
angle adapter (GEA FC2) or angle drill head
(GWA FC2)
Mounting the application tool in the keyless
chuck (GFA FC2), off-set angle adapter
(GEA FC2) or angle drill head (GWA FC2)
Changing the position of engagement
(GEA FC2)
Changing the position of engagement
(GWA FC2)
Bosch Power Tools
Figure Please observe
1
2
3
4
5
6
7
8
9
10
11
1 609 92A 14Z | (12.1.15)
English | 13
Page
204
204
204
205
205
206
206
207
207
208
208
