Betriebsanleitung/Operating manual
E3905 / P3394
11

Technical specifications

Measuring ranges:
Display range:
Resolution:
Pressure units:
Accuracy: (type.)
Temperature effect
Measuring rate:
Nominal temperature:
Sensor:
Pressure connection
Material of wetted parts
Overpressure safety
Electr. Connection:
Additional Functions:
Power-Off-Function:
Min/Max-Alarm:
Real time clock:
Logger:
Memory:
Cycle time CYCL:
Display:
Pushbuttons:
Interface:
Power supply:
40
max. -1999...9999 digit, depending on connected sensor
depending on connected sensor
mbar, bar, kPa, MPa, mmHg, PSI, selectable depending on
connected sensor
±0,2%FS opt .:0,1% (FASt and P.dET: ±0.5%FS)
±0,4%FS (0-50°C)
slow: 4 meas./sec (ConF-Rate = Slow)
fast: >100 meas./sec (ConF-Rate = FASt and P.dEt)
20°C
All sensors of the Manoport-series without re-calibration can be
connected
G1/2
stainless steel
see data sheet „Manoport"
Mini-DIN-Socket with locking mechanism
The sensor will automatically be detected, the measurement range
settings are set referring to sensor data
Device will be automatically switched off if no key is pressed / no
interface communication takes place for the time of the power-off
delay. The power-off delay can be set to values between 1 and 120
min.; it can be completely deactivated.
The measuring value is constantly monitored for the min. and max.
rails set.
Alarming is done by integrated horn, display and interface
Integrated clock with date and year
2 Functions: individual value logger („Func–Stor") and
cyclic logger („Func–CYCL")
Store: 99 data sets; CYCL: 1800 data sets or resp. 5400 (1 channel)
1...3600 seconds
2 four digit LCDs (12.4mm high and 7 mm high) for measuring values
and for min/ max memories, hold function, etc. as well as additional
functional arrows.
6 membrane keys
Serial interface (3.5mm jack) can be connected to RS232 interface of
a PC via electrically isolated interface adapter (see accessories).
9V battery, type: IEC 6F22 (included in scope of supply)
as well as additional d.c. connector (diameter of internal pin 1.9 mm)
for external 10.5-12V direct voltage supply.
