Safety Precautions; Product Parameters - Gens Ace Imars III Pro Bedienungsanleitung

● Before operating the device, please read all the following safety instructions.
Please follow all the instructions in the manual to ensure maximum safety.
Improper operation may cause property damage and/or serious injury to the
user.
● Never leave an operating charger unattended. If there is ANY problem during
charging. IMMEDIATELY disconnect the charger from it's power source.
● Be absolutely certain that the charge and discharge parameters are set
correctly for the battery you are charging. Incorrect settings may lead to
accidents.
● Ensure that the charger is kept away from heat and moisture during use, and
pay extra attention to ventilation and heat dissipation.
● Check the charger, battery and leads for damage before each use.DO NOT
under ANY circumstances use a damaged charger, battery or leads.
● Do not put metal debris into each interface, causing damage to the
equipment or injury to the user.
● This product is not a toy. Do not let children operate the charger.
● Do not disassemble this charger. There are no user serviceable parts inside.
● When you are done charging, immediately disconnect the battery from the
charger and disconnect the charger from your AC power source.
product model
Display type
Operating
temperature
Storage
temperature
Operating
humidity
Storage
humidity
Dimensions
Product
Net Weight
Accessories
included
Gens Ace ImarsIII

SAFETY PRECAUTIONS

PRODUCT PARAMETERS

ImarsIII Pro
Backlight 2x16 LCD
0~35℃
-10~55℃
45%~80%
10%~93%
146x87x40 mm
0.4kg
AC Input Cable
Balance adapter board
XT60-T plug adapter
XT60-EC3 adapter
XT60-EC5 adapter
14
Input Power
Charging Current
Maximum
charging voltage
Maximum
charging power
Maximum
discharging power
Discharge current
Cell Balancing
USB output
Supported battery
chemistries
100V~240VAC,
50~60Hz~1.5A
0.1~10A
26.4V
100W
5W
0.1~1.5A
2~6s
5V/2.4A
LiPo/LiFe/LiHv (1-6S)
NiMH charge (3-18S)
NiMH discharge (1-10S)
