Gens Ace Imars III Pro Bedienungsanleitung Seite 21

3.5 Button/Buzzer Sound Settings
COMMON ERRORS AND SOLUTIONS
NO
Error status
Balance port
1
error 1
Balance port
2
error 2
Over voltage
protection of
3
main port in
charger
interface
Over voltage
protection in
4
balance port
of charger
Enter/Start按键
Enter/Start按键
Enter/Start按键
Enter/Start按键
LED display
From the main charge menu press the +/-
button to switch to the "PRPGRAM SELECT
SYSTEM SET" menu
Click the Enter/Start button to enter the system
setting display, and click the +/- button to switch
to the "Key Beep/Buzzer" position;
Click the Enter/Start button, the cursor on the
right side of Key Beep flashes, and the status is
modified by clicking the +/ - button;
(ON: turn on the button sound, OFF: turn off the
button sound)
Click the Enter/Start button, the cursor on the
right side of Buzzer flashes, and the status is
modified by clicking the +/ - button;
(ON: turn on the buzzer sound, OFF: turn off the
buzzer sound)
Click the Enter/Start button.the set up is
completed
Reason of Error
Cell count is set
incorrectly
Cell count is set
incorrectly
The charger detected
the single cell voltage is
below 0.6V through the
balance port.
The battery voltage
exceeded the Max
charging voltage of
charger. The definition is
showed as below:
Lipo:4.5* Number of series
/LiHV :4.6* Number of
series
LiFe:4.0*s Number of
series /NiMH: 1.8* Number
of series
(Wrong battery type or
over voltage)
The voltage of single cell
exceeds the max setting
voltage.
Setting standard as below:
LIPO:4.5V/LIHV:4.6V
LIFE:4.0V/NIMH:1.8V
Solution
1.Click the button of Back /Stop to exit the
error status. 2.Check the cell count
setting and be certain it is correct for
battery being charged.
1.Click the button of Back /Stop to exit the
error status.
2.Check the cell count setting and be
certain it is correct for battery being
charged.
3.If the setting parameter is consistent with
the actual one, the abnormality still occurs.
Use the charger "PROGRAM SELECT LI
BATT METER" to read the voltage of each
cell and check it.
Check the balancing cables for poor
contact or breakage
1.Click the button of Back /Stop to exit the
error status.
2.Check he setting series and actual series
，if not match，revise setting series and
actual series consistently.
3. If you had set the charger and actual
series consistently, charger still shows the
error. Use the charger function"PROGRAM
SELECT LI BATT METER" to read every
cell 's voltage. If the total voltage has
exceeded the setting standard, please to
discharge the battery voltage standard or
below.
1.Click the button of Back /Stop to exit the
error status.
2.Use the charger function"PROGRAM
SELECT LI BATT METER" to read every
cell 's voltage. To discharge the voltage of
single cell or the total voltage of whole
battery, until the voltage of single cell is
below the setting standard.
Gens Ace ImarsIII
21
