KIKKA BOO 4 SAFE+ ISOFIX Gebrauchsanweisung Seite 6

WARNINGS!
• Do not install or use this child restraint system until you have fully read and understood the installation instructions provided by the restraint
system manufacturer.
• Do not install the child restraint system in the forward facing position on a seat tted with an airbag.
• Pay attention to all the red plastic parts or stickers on the safety seat, which show the belt guides for correct installation.
• All the belts that secure the restraint system to the vehicle must be tight; the straps that secure the child in the seat should be adjusted to t the child, and must not be twisted.
• Do not leave the child unattended in the safety seat.
• The safety seat should be replaced if it has been involved in an accident.
• Do not alter the product or make any additions to it without approval from the relevant authority.
• If the safety seat does not include the fabric cover, it should be kept out of sunlight, otherwise it may get too hot and burn the child' s skin.
• Any luggage or other objects that could cause injuries in the event of an accident must be properly secured.
• The child restraint system must not be used without the cover.
• The seat cover must not be replaced with any other than the one recommended by the manufacturer, because the cover is an integral part of the safety seat.
• The instructions should be kept with the safety seat throughout its use-life.
• Do not use any load bearing and connection points other than those listed in the instructions and marked on the restraint system.
• The rigid or plastic parts of the child restraint system must be positioned following the instructions so that, with daily use, they do not get trapped in the vehicle doors or mobile parts of
the seats.
• This product is a "universal" child restraint system. It is approved under Regulation No. 44, 04 series of amendments, for general use in vehicles and will t most, but not all, vehicle seats.
• A correct t is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle is suitable for any "universal" child restraint system for this age group.
• This child restraint system has been classi ed as "universal" as it complies with more stringent conditions than those, which applied to earlier
designs not carrying this notice.
• If in doubt, consult either the child restraint system manufacturer or the retailer.
• Recommended only for vehicles equipped with a 3-point seat belt, approved under UN/ECE Regulation No. 16 or other equivalent standard.
• IMPORTANT SAFETY NOTICE: Do not use this product on seats tted with airbags (SRS).
PARTS OF THE CAR SEAT:
A. Harness strap; B. Shoulder pad; C. Buckle; D. Crotch strap pad; E. Harness adjuster lever (above the strap); F. Iso x system; G. Vehicle seat belt route groove;
H. Headrest belt guide; I. Top tether;
GENERAL INFORMATION
1. FITTING THE BELT SYSTEM
CORRECT SHOULDER STRAP HEIGHT
Check if the shoulder straps are at the correct height for the child. The shoulder straps should always be inserted through the slots in the cover and the shell of the seat that are closest to
the top of the child' s shoulders.
2. ADJUSTING THE HEIGHT OF THE SHOULDER STRAPS
Step 2.1. Press the harness adjuster lever and pull both harness straps forward to loosen them.
Step 2.2. Turn the seat around, and from the back of the seat take the straps out of the metal junction plate.
Step 2.3. Pull the ends of the straps through the slots on the front of the seat and reinsert them through the required slots.
Step 2.4. Check if the harness straps are inserted through the same slots on both sides of the seat and make sure the straps are not twisted.
3. FASTENING THE SAFETY SEAT BUCKLE
Step 3.1. Slot the two metal sections of the buckle connectors together.
Step 3.2. Slot the two buckle connectors in the slot on the top of the buckle until they click into place.
Step 3.3. Check if the harness is correctly locked by pulling the shoulder straps upwards. To release the harness, press the red button on the buckle downwards.
4. TIGHTENING AND SLACKENING THE HARNESS
Adjust the harness system to be comfortable every time you place the child in the restraint system.
Step 4.1. Place the child in the child restraint system.
Step 4.2. Adjust the shoulder straps and the headrest height.
Step 4.3. Check if the straps are not twisted, bring the two metal parts together and slot them into the buckle.
Step 4.4. Tighten the harness straps as much as possible without causing the child any discomfort.
*To release the child, follow the instructions above in reverse order.
5. ADJUSTING THE HEADREST HEIGHT: 9 headrest height positions
As children are not all the same height, the headrest may be adjusted upwards or downwards. A correctly adjusted headrest ensures optimal protection for the child in the safety seat. Pull
the adjusting ring of the headrest upwards, move the headrest up or down, and release the adjuster to fasten the headrest in the required position. IMPORTANT: After each adjustment,
check if it is properly engaged by sliding the headrest downwards slightly.
6. INSTALL FOR GROUP 0+: ISOFIX+TOP TETHER
For Group 0+(from birth to 18KGS, from birth to 4years), the baby car seat should be installed rearward-facing, using ISOFIX and top tether to t the seat to vehicle seat. And use the
5-point safety belt to x the child.
Step 1: Turn the baby car seat to the full reclined position. Please check the blue mark on the base of child seat for reference. Turn the ISOFIX system to the front side of child seat pull the
red locker and lock the ISOFIX system.
Step 2: Place the child seat rmly against the back of forward-facing vehicle seat.
ENGLISH
