8. USE AND OPERATION

8.1 OPERATION AND INFLATION
1.
Select, among the various fittings supplied, the suitable adapter engaging inside and opening the
valve of the inflatable structure.
2.
Fit the selected adapter inside the fitting by inserting it on the hose end.
3.
To connect the hose, screw it on the inflation port (OUT).
4.
Select the desired pressure by turning the pressure gauge ring and placing the indicator until
reaching the desired value.
5.
Connect the inflator to the power supply using the cables provided.
6.
Press the start button (ON).
7.
Once the set pressure is reached, the inflator switches off automatically.
The inflator can be stopped at any time by pressing the stop button (OFF).
NOTE
The inflator is equipped with a plug for the car cigarette lighter and also with an adapter with crocodile
clips for the direct connection to the 12 Vdc battery.
WARNING
In case crocodile clips are used, make sure of the correct polarity (red clamp connected to
battery positive terminal).
Otherwise the inflator will not start.
WARNING
Do not run the inflator for more than 20 minutes and then let the unit cool down for 10
minutes before using it again.
WARNING
When the device is under pressure, never turn the pressure knob or the pressure gauge
ring counter-clockwise. This would cause the immediate breakage of the instrument.
WARNING
Take into account the maximum inflating pressure suitable to the object to be inflated.
Always set the maximum recommended pressure using the pressure knob or the pressure
gauge ring. Do not over inflate.
WARNING
Protect from sand, keeping the inflator inside the supplied bag: any sand entering the
inflator can cause it to jam.
8.2 BATTERY STATUS LIGHT INDICATOR
The brightness intensity of the LED, located under the pressure gauge ring, defines the battery level
status. Full brightness of the LED indicates a charged battery. An off LED indicates a low battery.
12
8.3 DEFLATION OPERATION
1.
Select, among the various fittings supplied, the suitable adapter engaging inside and opening the
valve of the inflatable structure.
2.
Fit the selected adapter inside the fitting by inserting it on the hose end.
3.
To connect the hose, screw it on the deflation port (IN).
4.
Connect the inflator to the power supply using the cables provided.
5.
Press the start button (ON).
6.
Press the stop button (OFF) once the inflatable unit has been emptied.
DURING THE DEFLATION PHASE, THE INFLATOR DOES
NOT SWITCH OFF AUTOMATICALLY.
Once the inflatable unit has been emptied, stop the inflator to avoid overheating the motor and all
risks associated.
8.4 ACCESSORIES
The accessories recommended for your inflator are available from your dealer or authorised service
centres.
WARNING
The use of any accessory not recommended for this inflator can be dangerous.
8.5 ANTI-SAND FILTER MAINTENANCE
The inflator is equipped with a filter seat located under the deflation fitting (IN). We recommend you to
keep it clean for inflator longer life and best performance.
8.6 HOW TO PERFORM THE ANTI-SAND FILTER CLEANING OPERATION
• Unscrew the two screws locking the deflation fitting (IN).
• Lift the fitting and remove the filter.
• Clean with compressed air or replace it if too dirty.
• Reassemble the fitting and screw the retaining screws.

9. TROUBLESHOOTING

POSSIBLE CAUSE
PROBLEM
Power cable not properly
connected.
The inflator does No battery voltage.
not start
The ON button has not been pressed.
The device is damaged
Hose wrong connection.
The inflator
does not inflate/
deflate
Wrong pressure setting.
POSSIBLE SOLUTION
Connect the power cable correctly
and with the right polarity (red clamp
to battery positive terminal).
Check battery conditions.
Press the ON key.
Contact a SCOPREGA service
centre.
Connect the air hose to the
correct port.
Correct pressure setting.
