English
3. Layout & Connections
3.2 Connections
12-24V DC Connector:
USB 3.2 Gen 1 A-Port:
StdB_SSTX +
StdB_SSTX -
VCC
USB 3.2 Gen 1 C-Port:
Note!
By dual assignment of the pins, the USB-C plug can be plugged into the port on both sides.
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
ATTENTION!!!
Use only with Power Supply which is included in delivery!
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
GND
D- D+
Attention!
Never plug in with force
or in wrong direction.
10
EX-1191HMVS-PD
