Technical Data
CAPACITY AND POWER CONSUMPTION
kPa Pu
6 0
6
50
8
40
4
30
2
20
1 0
0
200 400 600
6
10
4
2 0
30
kW P
Th e capacity curves for Dustcontrol vacuum producers have been measured
and are stated empirically. Outlet pressure losses from a normal outlet (silen-
cer, back-fl ow valve/bend) have been accounted for in the curve. Additional
equipment such as a diff user can result in increased pressure loss and must be
taken into consideration.
Stated air-fl ows are for standard air (101.3 kPa@ 20

Dimensions and Arrangements

2011-01-26
All manuals and user guides at all-guides.com
7
5
3
1
800 1000 1200 1400 1600
1
2
3
5
8
o
C).
TPR 35, TPR 40, TPR 43, TPR 47, TPR 50
TPR 40, 15kW - 16
1. TPR 35 11 kW
2. TPR 40 15 kW
3. TPR 43 18,5 kW
Q
4. TSR 43 18,5 kW
5. TPR 47 22 kW
3
m /h
6. TSR 47 22 kW
7. TPR 50 30 kW
8. TSR 50 30 kW
7
Th e stated curves are for negative application, all pressures stated are
assumed to be below relative atmospheric pressure at sea level. Th ese
devices can also be used for positive pressure application and will
generate a greater pressure diff erential.
Part No 9045
