Safety Considerations

Read all instructions before the machine/installation is
commissioning.
Th e equipment must be installed and maintained properly
by qualifi ed personnel who have study this user instruction.
Dustcontrol does not take responsibility for defective instal-
lation or maintenance.
Warning! When using electric machines, basic safety
precautions should always be followed to reduce the risk
of fi re, electric shock and personal injury, including the
following:
1. Work area environment
Keep the area around the central unit clean. Do not
store or work with fl ammable liquids or gases near
the machine.
2. Overload
If there is an alarm signal it should be carefully
checked out to see that the machine is un damaged. If
there are any damaged parts these should be repaired
by a Dustcontrol authorized service centre. Always
follow the regulations pertinent to the material you
are working with. Do not use the machine for pur-
poses that it is not intended for.
3. Bodily injuries
Warning - High negative pressure
Do not start the pump without having it connected
to the duct work. Do not adjust the vacuum relief
valve while the pump is operating. Never let the

Technical Data

,
TECHNICAL DATA
description
Pump RPM
Weight
Max dP
Nominal pressure
Max Q
Sound level of unit 1 m dB(A)
Inlet/Outlet
* Standard DC Green System, Max 22 kPa
All manuals and user guides at all-guides.com
TPR 40
rpm 4000
kg 400
kPa 26*
kPa 20
m 3 /h 1200
66
Ømm 160/160
TPR 40, 15 kW - 15
suction come in contact with parts of the body, for
example a hand. Th e pump generates a high negative
pressure, severe injury may result.
Warning - Very hot exhaust air
Exhaust air can be very hot, up to 150
4. Electricity
A separate lockable disconnect must be installed
where it is readily accessible to the pump. Do not
repair the electric components yourself, get somebo-
dy qualifi ed. Faults may cause injury. Th e electrical
connections may only be performed by a certifi ed
electrician. See also under section 7, 'Warning'.
5. Important measure
Th e electrical disconnect should be locked in the
"off " position before demounting the safety panels or
ducting.
6. Checking for damage
Check the machine regularly for damage. If there
are any damaged parts these should be repaired by a
Dustcontrol authorized service centre.
7. Warning
Use only accessories and replaceable parts which are
available in Dustcontrol catalogue. When using non-
genuine parts, especially fi lters and plastic sacks, dust
leaks could occur which may be hazardous to health.
POWER RATING
PART NO/MOTOR Hz TPR 40
230 V 50 106802/15 kW
400 V 50 106800/15 kW
460 V USA/CAN 60 106805/20 HP
575 V CAN 60 106806/20 HP
O
C.
Part No 9045
