COMPACT
EN
ALL MODELS EXCEPT EURO 6 - Electric wiring
Take care not to invert polarities when connecting the unit to the power supply. If this were to
happen, the plate would not come on and the unit would not work.
Blower
2,6 Amp.
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Compressor
electronic
module
All manuals and user guides at all-guides.com
IMPORTANT WARNING!
Na
Electronic
module
10 A. Fuse
-
+
+
F
D
C
P
T
Compressor
ºC
ºF
ON/OFF
TEMP
Wiring strip
Comsuption 30 mAmp.
12
Air conditioning for vehicles
Temperature
probe
NTC 15KΩ a 25º
Fan
2,9 Amp.
PWM.
Compressor
electronic
module
-
+
+
F
D
C
P
T
Compressor
