STATUS SIGNALLING
Searchline Excel Plus is equipped with a high visibility LED status indicator.
Refer to Operation section of Technical Manual for more information.
WARNING
!
LED status indicator behaviour is configurable. If LED status indicator is configured differently from the
default setting, it may indicate states different to other outputs.
Operation Colour
without
Bluetooth
Fault Yellow flashing
Inhibit Yellow steady
Warning Yellow flashing with
green alternating
Normal Green steady
Normal Green flashing
Normal None
Alarm Red flashing
Over-range Red flashing
Operation Colour
with
Bluetooth
Fault Yellow flashing
Inhibit Yellow steady
Warning Yellow flashing with
green alternating
Normal Blue steady
Normal Blue flashing
Alarm Red flashing
Over-range Red flashing
Connecting Blue flashing
Connected Blue steady
Warning Blue alternating
Scheme
Default
Default
Default
Default
Optional
Optional
Default
Default
Scheme
Default
Default
Default
Default
Optional
Default
Default
Default
Default
Default
(7)
