OPERATION, MOUNTING RDP-01
1. Disconnect power supply by the phase fuse, the circuit-breaker or the switch-discon-
nector combined to the proper circuit.
2. Check if there is no voltage on connection cables by means of a special measure
equipment.
3. Connect the cables with the terminals in accordance with the installing diagram.
4. Install RDP-01 device in installation cable box.
5. Switch on the power supply from the mains.
RDP-01 can operate in five modes:
COMFORT (Available only in cooperation with 4 push-button transmitter). In this mode
the following two functions are realised:
ONE PUSH-BUTTON Pressing the programmed push-button shortly (<0.8 sec.) caus-
es the dimmer to operate in the range of switch on/switch off (to the last adjustment of
lighting luminous density level), however pressing the programmed push-button longer
(>0.8 sec.) causes alternate lighting brightening - dimming.
TWO PUSH-BUTTONS SWITCH ON pushbutton: pressing the programmed push-
button shortly (<0.8 sec.) causes the lighting switches on according to the last adjust-
ment of lighting luminous density level, however pressing the programmed push-button
longer (>0.8 sec.) causes lighting brightening to the maximum level. SWITCH OFF
pushbutton: pressing the programmed push-button shortly (<0.8 sec.) causes the
lighting switches off, however pressing the programmed push-button longer (>0.8 sec.)
causes lighting dimming to the minimum level.
TIME The device after pressing the pushbutton switches on according to the adjusted
time (tp), then it switches off automatically. Another pressing of the push-button during
time countdown causes the lighting is switched off before adjusted time finishes. Default
settings - 15 seconds.
CAUTION! Adjusted time will not be deleted.
RADIO TRANSMITTERS PROGRAMMING
COMFORT mode:
1. Press RNK-04 transmitter's push-button for a longer time.
2. Press PROG push-button of RDP-01 device for a longer time until LED red diode
switches on (constant signal). Next release PROG push-button.
3. Release transmitter's pushbutton. LED red diode switches on (first signal pulsates,
next the signal is constant).
4. Press the same transmitter's pushbutton and release it. LED red diode switches on
(the signal pulsates) and next it switches off - THE TRANSMITTER IS ADDED.
ONE PUSH-BUTTON mode:
1. Press PROG push-button of RDP-01 device for a longer time until LED red diode
switches on (constant signal). Next release PROG push-button.
2. Press the transmitter's push-button for a longer time. LED red diode switches on (first
signal pulsates, next the signal is constant).
3. Release transmitter's push-button. LED red diode switches on (the signal pulsates),
next the LED red diode switches off - it means the TRANSMITTER IS ADDED.
SWITCH ON/SWITCH OFF mode (two push-buttons):
1. Press PROG push-button of RDP-01 device for a longer time until LED red diode
switches on (constant signal). Next release PROG push-button.
2. Press and release transmitter's first push-button. LED red diode switches on (first
signal pulsates, next the signal is constant).
3. Press and release the second transmitter's push-button. LED red diode switches on
(the signal pulsates) and next it switches off - THE TRANSMITTER IS ADDED.
TIME mode (one push-button):
1. Press PROG push-button of RDP-01 device for a longer time till LED red diode
switches on (constant signal). Next release PROG push-button.
