T
RANSPORTING THE
Overtightening of chains or straps through Tie Down lugs may result in
damage to the work platform.
XRT Electric
W P
ORK LATFORM
B C
Y RANE
1. Secure straps to chassis Tie Downs/Lifting Lugs
only.
B T
Y RUCK
1. Maneuver the work platform into transport position
and chock the wheels. The platform must be in the
fully lowered position for transport.
2. Secure the work platform to the transport vehicle
with chains or straps of adequate load capacity
attached to the front and rear Lift/Tie Down points on
both sides of the chassis.
C A U T I O N
!
Figure 9: Transporting the Work Platform
FRONT TIE DOWNS / LIFTING LUGS
REAR TIE DOWNS / LIFTING LUGS
!
11
