English 1 INSTALLATION 1) Remove the balance, draft shield, top pan, AC adapter and pan support from the packaging 2) Remove the shipping protection screw and transit disc from the top of the balance and place the plastic top pan support on the balance. Do not use excessive force when removing and installing the screw.
English 1.1.1 LOCATING AND PROTECTING YOUR BALANCE In order to keep your balance functioning at its best we suggest that you do the following: Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents. Make sure the balance is located on a strong table and free from vibration.
English 1.1.2 STORING WHEN NOT IN USE *You can store them easily on top of each other to save space and protect them from damage. Without Shield With Shield *Only applies to 120mm top pan versions...
English 3 DISPLAY and KEYPAD 3.1.1 Display Percentage symbol Low battery indicator Hold symbol Zero Net symbol Units symbol Stable Capacity tracker Weighing digits 3.1.2 Keypad FUNCTION TO POWER UP BALANCE ON/OFF TARE/ZERO TO RE ZERO OR DEDUCT WEIGHT OF EMPTY CONTAINER SMPL TO ENTER AND OPERATE COUNTING MODE (sample)
English 4 OPERATION 4.1.1 Zero/Tare • To zero the balance, press the [Tare/Zero] key and the reading will show zero, the symbol “>O<” will be displayed • P ut a container on the pan and the display will show its weight. •...
English 4.1.3 Percent Weighing This is used to measure the percentage between the sample weight and a standard weight. E.g. Put your standard weight onto the pan and press the [%] key, the display will show 100.0%.per. This would then be taken as the standard weight. Remove the standard weight and the reading goes to zero, the display will show 0.0%.
English readings, the display will show “2 ACC” for 1 second 4.1.7 Automatic accumulation I n this mode, place the weight onto the pan, after the stable symbol shows the reading will be accumulated automatically. The display will show ”ACC X”...
English 5 PARAMETER SETTINGS Users can press the [Unit] key to view and change parameter settings when the scale is counting down from POWER UP. The balance has 5 parameters that can be set by the user. FUNCTION SECTION DESCRIPTION Sets the units to be used See section 5.1 UNIT F1...
English U nits and conversion rates unit conversion symbol Carats Grains 15.432358 Newtons 0.009808 Drams 0.5643834 Pounds 0.002205 Ounce 0.035274 Ounce 0.03215075 Troy Taels T. 0.0266667 TL.t Taels Hk. 0.026717 TL.H Taels S. 0.026455 TL.S User setting 5.1.2 Backlight setting The backlight may be enabled or disabled by the user.
English 5.1.3 Communication When the display shows “SEr F3” press [Tare/Zero] to enter the communication settings. The following options are available for setting the output and accumulation functions: Mode Print Feature Accumulation Data is sent whenever the [Print] Manual accumulation when Prn 232 key is pressed.
English 5.1.6 Format settings The scale will print either using a format that includes stability • indications or one with only the weight. There are 2 settings that can work as follows FOR 1 Data format is with line headings and extra line feeds as shown in section 7 FOR 2...
“FAlL H”. If the weight placed on is less than 90% of calibration weight value selected, the display will show “FAlL L”. Users should recalibrate the balance following the correct operation.+ Calibration weights: MP700625 MP700626 MP700627 MP700628 Model Weights(g)...
English 7 COMMUNICATIONS See parameters 5.3 Setting The Printing Parameters / Accumulation section for full information on settings The standard Interface parameters are: RS-232 output of weighing data ASCII code 4800 Baud 8 data bits No Parity Connection details are: Generally a Null model cable is RS-232 Connector: 9 pin d-subminiature socket required for...
Seite 19
English Format 2 Output: The output will be the same value as is on the display. If in parts counting it will displayed as PCS, if in weighing it is only the weight. An example output is : ± _ _ _ _ _ _ 1 2 3 . 4 5 _ g _ <cr> <lf> Parts Counting example: ±...
English 8 ERROR MESSAGES If an error message is shown, repeat the step that caused the message. If the error message is still shown then contact your dealer for support. Reason code Description Solution There might be weight on the pan when the scale is Remove weights OVER...
Français 9 INSTALLATION 1) Retirez la balance, la cage de protection, le plateau, l’adaptateur AC et le support du plateau de son emballage. 2) Retirez la vis de protection et le couvercle de transit du dessus de la balance et mettez le support du plateau sur la balance. Ne pas forcer excessivement lorsque vous vissez ou dévissez la vis de protection pour le transport.
Seite 22
Français Evitez les températures extrêmes. Ne pas la placer sous les rayons directs du soleil ou proche d’un ventilateur ou climatiseur. Soyez sûr que la balance soit localisée sur une table stable et sans vibration Evitez des sources d’alimentations instables. Ne pas fonctionner prés de gros utilisateurs d’électricités tels que les postes à...
Seite 23
Français 9.1.2 RANGEMENT APRES USAGE Vous pouvez les empiler facilement les unes sur les autres pour économiser de la place et les protéger de tout endommagement. Sans cage de protection Avec cage de protection...
Français 11 ECRAN et CLAVIER 11.1.1 Ecran Symbole pourcentage Indicateur batterie faible Symbole Hold Zéro Symbole net Stable Symboles unités Indicateur de capacité Chiffres pesage Clavier Touche Fonction ALLUME LA BALANCE ON/OFF REMISE A ZERO OU DEDUCTION DU POIDS D’UN RECIPIENT TARE/ZERO VIDE SMPL...
Français 12 FONCTIONNEMENT 12.1.1 Zero/Tare • Pour la mise à zéro de la balance appuyez sur [Tare/Zero] et la lecture affiche zéro, le symbole “>O<” sera affiché. • Mettez un récipient sur le plateau et l’écran affichera son poids. • Appuyez sur [Tare/Zero] pour tarer le poids du récipient de la balance, l’écran affichera maintenant zéro ainsi que les symboles zéro et NET.
Français 12.1.3 Pesage en Pourcentage Ce mode est utilisé pour mesurer le pourcentage entre le poids échantillon et un poids standard. Par exemple, mettez votre poids standard sur le plateau et appuyez sur [%], l’écran affichera 100.0%.per. Ceci sera considère comme le poids standard. Retirez le poids standard et la lecture revient à...
Français poids sur le plateau et suivez la même procédure pour accumuler les lectures, l’écran affichera “2 ACC” pendant 1 seconde. 12.1.7 Accumulation automatique Dans ce mode, mettez le poids sur le plateau, après que le symbole stable ait été affiché la lecture sera accumulée automatiquement. L’écran affichera ”ACC X”...
Français 13 PARAMETRES DE REGLAGE Les utilisateurs peuvent appuyez sur [Unit] pour visualiser et modifier les à paramètres de réglage lorsque la balance effectue son compte rebours initiale lors de la mise en marche. La balance possède 5 paramètres qui peuvent être réglés par l’utilisateur. FONCTION SECTION DESCRIPTION Voir section 13.1...
Français Unités et taux de conversion Unité conversio symbole Carats Grains 15.432358 Newtons 0.009808 Drams 0.5643834 Pounds 0.002205 Ounce 0.035274 Ounce 0.0321507 Troy Taels T. 0.0266667 TL.t Taels Hk. 0.026717 TL.H Taels S. 0.026455 TL.S User setting 13.1.2 Réglage du rétro éclairage Le rétro éclairage peut être activé...
Seite 31
Français 13.1.3 Communication Quand l’écran affiche “SEr F3” appuyez sur [Tare/Zero] pour entrer dans les réglages de communication. Les options suivantes sont disponibles pour le réglage de sortie et les fonctions d’accumulations: Mode Fonction impression Accumulation Les données sont envoyées toutes Accumulation manuelle Prn 232 les fois que [Print] est actionnée.
Français • 1200bps、 2400bps、 4800bps、 9600bps • Appuyez sur [Tare/Zero] pour changer le réglage et retourner au mode réglage de communication, • Appuyez sur [Print] pour sortir du mode communication. 13.1.6 Réglages du format La balance imprimera soit en utilisant un format qui comprend les •...
Seite 33
Français 13.1.9 Paramètres techniques L orsque l’écran affiche “TECH F5” appuyez sur [Tare/Zero] pour entrer dans le menu des réglages des paramètres techniques et ensuite entrer le code PIN revendeur. C’est accès est uniquement pour les revendeurs.
“FAlL H”. Si le poids utilisé est inferieur à 90% de la valeur du poids de calibrage sélectionné, l’écran affichera “FAlL L”. Les utilisateurs doivent re-étalonner la balance en suivant la procédure adéquate. Poids de calibrage: MP700625 MP700626 MP700627 MP700628 Modèle Poids(g)...
Français 15 COMMUNICATIONS Voir la section des paramètres 13.3 Réglage des Paramètres d’impression / Accumulation pour des informations complètes sur les réglages Les paramètres de l’interface standard sont: RS-232 sortie des données de pesage Code ASCII 4800 Baud 8 bits de données Aucune Parite Détails de la connexion sont: Généralement un câble modèle Null...
Seite 36
Français Si la balance est réglée sur sortie continue le poids seulement est imprimé suivi de 2 lignes vides. Un exemple de sortie continue est illustré ci-dessous. G T , N T ± _ _ _ _ _ 1 2 3 . 4 5 _ g _ <cr> <lf> Inclus 2 lignes vides <cr>...
Français 16 MESSAGES D’ERREUR Si un message d’erreur est affiché, répétez l’étape que aurait provoqué ce message. Si l’erreur est encore visible alors contactez votre fournisseur pour assistance. Raison code Description Solution Il peut y avoir des poids sur le plateau quand la balance Retirez les poids OVER A/D surcharge...
Deutsch 17 INSTALLATION 1) Nehmen Sie Waage, Windschutz, Wägeplatte, Netzadapter und Täger für die Wägeplatte aus der Verpackung. 2) Entfernen Sie die Sicherungsschraube und –scheibe an der Oberseite der Waage, und setzen Sie den Plastikträger für die Wägeplatte auf die Waage. Wenden Sie beim Entfernen und Anbringen der Schraube nicht zu viel Kraft auf.
Deutsch 17.1.1 AUFSTELLORT SCHUTZMASSNAHMEN FÜR IHRE WAAGE Um Ihre Waage funktionsfähig zu halten, raten wir, folgende Punkte zu beachten: Vermeiden Sie extreme Temperaturen. Nicht in direktem Sonnenlicht oder nahe Klimaanlagen aufstellen. Stellen Sie sicher, dass die Waage auf einem stabilen Tisch steht, und keinen Vibrationen ausgesetzt ist Instabile Energiequellen vermeiden.
Deutsch 19 ANZEIGE und TASTATUR 19.1.1 Anzeige Symbol Prozentwägung Batterieanzeige Symbol Haltefunktion Null Netto-Symbol Stabil Symbole für Einheiten Kapazitätsanzeige Wägeziffern 19.1.2 Tastatur Funktion EIN-/AUSSCHALTEN DER WAAGE ON/OFF TARE/ZERO RÜCKSETZEN AUF NULL ODER TARIEREN DES GEWICHTS EINES LEEREN BEHÄLTERS AUFRUFEN UND ANWENDUNG DER ZÄHLFUNKTION SMPL (sample) AUSWAHL DER BENÖTIGTEN WÄGEEINHEIT...
Deutsch 20 BETRIEB 20.1.1 Auf null stellen /Tarieren • M it der Taste [Tare/Zero] wird die Waage auf null gestellt. In der Anzeige wird Null angezeigt, und das Symbol >O< ist an. • W ird ein Behälter auf die Waage gestellt, wird dessen Gewicht angezeigt. •...
Deutsch 20.1.3 Prozentwägung Hiermit wird das prozentuelle Verhältnis zwischen einer Probe und einem Referenzgewicht ermittelt. Beispiel: Geben Sie ein Referenzgewicht auf die Waage; drücken Sie die [%] Taste. Die Anzeige wechselt zu 100.0%. Dies ist das Referenzgewicht. Entfernen Sie das Gewicht von der Waage. Die Anzeige steht nun auf 0%. Geben Sie nun die Probe auf die Waage.
Deutsch Wägemodus zurück. • E ntfernen Sie das Gewicht, so dass die Waage Null anzeigt, und legen Sie dann ein neues Gewicht auf. Folgen Sie dem oben beschriebenen Ablauf, um auch den neuen Wert zum Summenspeicher hinzuzufügen. Die Anzeige zeigt für 1 Sekunde “2 ACC”...
Deutsch 21 PARAMETEREINSTELLUNGEN Anwender können die Parameter einsehen und ändern, indem sie während des Zähldurchlaufs beim Einschalten der Waage auf [Unit] drücken. Die Waage hat 4 Parameter, die vom Anwender eingestellt werden können. FUNKTION ABSCHNITT BESCHREIBUNG Siehe Abschnitt 21.1 Aktiviert die Einheiten, die verwendet werden sollen UNIT F1 g / ct / GN / N / dr / Lb / oZ / oZt / tl t / tl H / tl S /CUS.
Seite 48
Deutsch Einheiten und Umrechnungsfaktoren Einheit Umrechnungs Symbol faktor Karat Grain 15.432358 Newton 0.009808 Dram 0.5643834 Pfund 0.002205 Unze 0.035274 Troy- 0.03215075 Unze Taels T. 0.0266667 TL.t Taels Hk. 0.026717 TL.H Taels S. 0.026455 TL.S Anwender spezifisch 21.1.2 Einstellen der Hintergrundbeleuchtung Der Anwender kann die Hintergrundbeleuchtung aktivieren oder deaktivieren.
Deutsch 21.1.3 Datenkommunikation Sobald "Ser F3" angezeigt wird, gelangen Sie mit [Tare/Zero] in das Menü zum Einstellen der Datenkommunikation. Folgende Optionen sind zum Einstellen der Ausgabe- und Summierfunktionen einstellbar: Mode Ausgabeweise Summierung Daten werden bei jedem Drücken von Manuelle Summierung Prn 232 [Print] gesendet.
Deutsch Formateinstellungen • DIe Waage druckt entweder ein Format, das Angaben zu Stabilitat beinhaltet, oder eines, das nur das Gewicht angibt. Es gibt 2 Einstellungen, die wie folgt aussehen: FOR 1 Datenformat mit Kopfzeile und extra Zeilenvorschub, siehe Abschitt 23 FOR 2 Datenformat Gewicht...
Anzeige “FAlL H”. Ist das If the weight placed on is less than 90% of Kalibrierung weight value selected, the Anzeige will show “FAlL L”. Users should recalibrate the balance following the correct operation.+ Kalibriergewichte: MP700625 MP700626 MP700627 MP700628 Modell Gewichte(g)...
Deutsch 23 ANSCHLÜSSE Siehe Abschnitt 21.3 bezüglich Druckparameter / Summiereinstellugen für ausführliche Informationen zu den Einstellungen. Parameter der Standard-Schnittstelle sind: RS-232 Ausgabe der Wägedaten ASCII Code 4800 Baud 8 Datenbit Keine Parität Anschlussdetails: RS-232 Connector: 9 pin d-subminiature socket Generell wird ein Pin 2 Output Nullmodem-Kabel für die...
Seite 53
Deutsch Steht die Anzeige auf Null, wird kein Gewicht ausgegeben. Ist die Waage auf fortlaufenden Ausdruck eingestellt, wird nur das Gewicht ausgedruckt, gefolgt von 2 Leerzeilen. Ein Beispiel für fortlaufenden Ausdruck sieht aus wie folgt: G T , N T ± _ _ _ _ _ 1 2 3 . 4 5 _ g _ <cr> <lf> Fügt 2 Leerzeilen ein <cr>...
Deutsch 24 FEHLERMELDUNGEN Wird eine Fehlermeldung angezeigt, wiederholen Sie den Schritt, der die Meldung verursacht hat. Erscheint die Meldung erneut, kontaktieren Sie bitte Ihren Händler. Code Beschreibung Mögliche Ursache Lösung Evtl. Gewicht auf der Waage OVER beim einschalten. Gewicht entfernen A/D überlastet Erneut kalibrieren Kalibrierung fehlgeschlagen.
Manufacturer’s Declaration of Conformity This product has been manufactured in accordance with the harmonised European standards, following the provisions of the below stated directives: Electro Magnetic Compatibility Directive 2004/108/EC Low Voltage Directive 2006/95/EC FCC COMPLIANCE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
