TIMING SPECIFICATION

MODE AT PRODUCTION
RESOLUTION
CLOCK
--HORIZONTAL--
H-FREQ
H. TOTAL
H. BLK
H. FP
H. SYNC
H. BP
H. ACTIV
--VERTICAL--
V. FREQ (HZ)
V. TOTAL
V. BLK
V. FP
V. SYNC
V. BP
V. ACTIV
--SYNC--
INT(G)
EXT (H/V) /POLARITY
EXT (CS) /POLARITY
INT/NON INT
MODE 1 MODE 2
640 X 480 1600 X 1200
25.175 MHz 229.500 MHz
31.469 kHz 106.250 kHz
usec
31.778
6.356
0.636
3.813
1.907
25.422
59.940 Hz 85.000 Hz
lines
525
45
10
2
33
480
NO
YES N/N YES P/P
NO
NON INT NON INT
— 5 —
usec
9.412
2.440
0.279
0.837
1.325
6.972
lines
1250
50
1
3
46
1200
NO
NO
CPD-E530
