1-6. D BOARD REMOVAL

Connector (4P)
GND
All manuals and user guides at all-guides.com
5
Five screws
6
(+BVTP 3 x 10)
A1 board
1
(C block)
Connector (4P)
CN605
CN701
CN601
Two screws
4
(+BVTP 3 x 10)
Rear plate assembly
CN1601
CN1600
CN1103
CN1003
CN501
CN602
— 12 —
Video block assembly
3
CN315
Two screws
2
(+BVTP 3 x 8)
GND
D board
8
Screw (+BVTP 3X10)
7
CPD-E530
