REF. NO. PART NO. DESCRIPTION
A1
* A-1299-419-A A1 BOARD, COMPLETE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC
C004 1-164-004-11 CERAMIC CHIP
C005 1-164-004-11 CERAMIC CHIP
C007 1-164-489-11 CERAMIC CHIP
C009 1-126-960-11 ELECT
C010 1-126-947-11 ELECT
C011 1-106-220-00 MYLAR
C012 1-164-489-11 CERAMIC CHIP
C014 1-107-930-91 ELECT
C015 1-164-004-11 CERAMIC CHIP
C016 1-128-528-11 ELECT
C017 1-163-251-11 CERAMIC CHIP
C018 1-107-649-11 ELECT
C019 1-163-021-91 CERAMIC CHIP
C021 1-163-021-91 CERAMIC CHIP
C022 1-126-947-11 ELECT
C023 1-164-489-11 CERAMIC CHIP
C024 1-107-909-11 ELECT
C025 1-163-021-91 CERAMIC CHIP
C026 1-163-227-11 CERAMIC CHIP
C027 1-126-785-11 ELECT
C029 1-164-489-11 CERAMIC CHIP
C031 1-162-318-11 CERAMIC
C032 1-164-004-11 CERAMIC CHIP
C033 1-164-004-11 CERAMIC CHIP
C035 1-104-574-11 CERAMIC
C036 1-163-251-11 CERAMIC CHIP
C037 1-164-004-11 CERAMIC CHIP
C038 1-163-017-00 CERAMIC CHIP
C039 1-115-339-11 CERAMIC CHIP
C040 1-163-021-91 CERAMIC CHIP
C042 1-115-339-11 CERAMIC CHIP
C043 1-164-004-11 CERAMIC CHIP
C045 1-164-004-11 CERAMIC CHIP
C046 1-163-021-91 CERAMIC CHIP
All manuals and user guides at all-guides.com
VALUES
0.001µF 10% 500V
0.1µF 10% 25V
0.1µF 10% 25V
0.22µF 10% 16V
1µF 20% 50V
47µF 20% 35V
0.1µF 10% 100V
0.22µF 10% 16V
22µF 20% 100V
0.1µF 10% 25V
470µF 20% 25V
100pF 5% 50V
2.2µF 20% 250V
0.01µF 10% 50V
0.01µF 10% 50V
47µF 20% 35V
0.22µF 10% 16V
47µF 20% 50V
0.01µF 10% 50V
10pF 0.50pF 50V
47µF 20% 10V
0.22µF 10% 16V
0.001µF 10% 500V
0.1µF 10% 25V
0.1µF 10% 25V
0.0047µF 10% 2KV
100pF 5% 50V
0.1µF 10% 25V
0.0047µF 10% 50V
0.1µF 10% 50V
0.01µF 10% 50V
0.1µF 10% 50V
0.1µF 10% 25V
0.1µF 10% 25V
0.01µF 10% 50V
— 37 —
REF. NO. PART NO. DESCRIPTION
C048 1-163-021-91 CERAMIC CHIP
C049 1-163-021-91 CERAMIC CHIP
C050 1-115-339-11 CERAMIC CHIP
C051 1-115-339-11 CERAMIC CHIP
C053 1-164-004-11 CERAMIC CHIP
C054 1-164-004-11 CERAMIC CHIP
C055 1-163-235-11 CERAMIC CHIP
C057 1-126-947-11 ELECT
C058 1-163-224-11 CERAMIC CHIP
C059 1-164-004-11 CERAMIC CHIP
C061 1-163-255-11 CERAMIC CHIP
C062 1-164-004-11 CERAMIC CHIP
C063 1-163-021-91 CERAMIC CHIP
C064 1-126-382-11 ELECT
C065 1-107-882-91 ELECT
C090 1-163-021-91 CERAMIC CHIP
C091 1-126-960-11 ELECT
C092 1-163-021-91 CERAMIC CHIP
C101 1-163-233-91 CERAMIC CHIP
C105 1-164-004-11 CERAMIC CHIP
C106 1-137-857-21 MYLAR
C108 1-164-489-11 CERAMIC CHIP
C109 1-126-947-11 ELECT
C111 1-163-251-11 CERAMIC CHIP
C120 1-126-947-11 ELECT
C123 1-136-189-00 MYLAR
C130 1-164-489-11 CERAMIC CHIP
C152 1-126-947-11 ELECT
C201 1-163-233-91 CERAMIC CHIP
C205 1-164-004-11 CERAMIC CHIP
C206 1-137-857-21 MYLAR
C208 1-164-489-11 CERAMIC CHIP
C211 1-163-251-11 CERAMIC CHIP
C220 1-126-947-11 ELECT
C223 1-136-189-00 MYLAR
C230 1-164-489-11 CERAMIC CHIP
C252 1-126-947-11 ELECT
C301 1-163-231-11 CERAMIC CHIP
C305 1-164-004-11 CERAMIC CHIP
C306 1-137-857-21 MYLAR
C308 1-164-489-11 CERAMIC CHIP
C311 1-163-251-11 CERAMIC CHIP
C319 1-163-021-91 CERAMIC CHIP
CPD-E530
A1
VALUES
0.01µF 10% 50V
0.01µF 10% 50V
0.1µF 10% 50V
0.1µF 10% 50V
0.1µF 10% 25V
0.1µF 10% 25V
22pF 5% 50V
47µF 20% 35V
7pF 0.25pF 50V
0.1µF 10% 25V
150pF 5% 50V
0.1µF 10% 25V
0.01µF 10% 50V
100µF 20% 16V
100µF 20% 16V
0.01µF 10% 50V
1µF 20% 50V
0.01µF 10% 50V
18pF 5% 50V
0.1µF 10% 25V
0.47µF 10% 250V
0.22µF 10% 16V
47µF 20% 35V
100pF 5% 50V
47µF 20% 35V
0.1µF 10% 250V
0.22µF 10% 16V
47µF 20% 35V
18pF 5% 50V
0.1µF 10% 25V
0.47µF 10% 250V
0.22µF 10% 16V
100pF 5% 50V
47µF 20% 35V
0.1µF 10% 250V
0.22µF 10% 16V
47µF 20% 35V
15pF 5% 50V
0.1µF 10% 25V
0.47µF 10% 250V
0.22µF 10% 16V
100pF 5% 50V
0.01µF 10% 50V
