Sony Trinitron CPD-E530 Serviceanleitung Seite 38

NOTE: The components identified by shading
and mark are critical for safety. Replace only
!
with part number specified.
REF. NO. PART NO. DESCRIPTION
C320 1-126-947-11 ELECT
C323 1-136-189-00 MYLAR
C330 1-164-489-11 CERAMIC CHIP
C352 1-126-947-11 ELECT
CONNECTOR
CN303 1-695-915-11 TAB (CONTACT)
CN307 1-794-991-11 CONNECTOR, D SUB
CN309 1-794-991-11 CONNECTOR, D SUB
* CN315 1-778-682-11 PIN, CONNECTOR (PC BOARD)
CN318 1-764-101-11 PIN, CONNECTOR (PC BOARD)
DIODE
D001 8-719-801-78 DIODE
D002 8-719-109-89 DIODE
D003 8-719-109-89 DIODE
D004 8-719-062-51 DIODE
D005 8-719-062-51 DIODE
D006 8-719-801-78 DIODE
D007 8-719-109-89 DIODE
D008 8-719-109-89 DIODE
D009 8-719-109-89 DIODE
D010 8-719-109-89 DIODE
D011 8-719-109-89 DIODE
D012 8-719-062-51 DIODE
D013 8-719-911-19 DIODE
D014 8-719-911-19 DIODE
D016 8-719-109-89 DIODE
D019 8-719-062-51 DIODE
D101 8-719-062-51 DIODE
D104 8-719-052-12 DIODE
D105 8-719-052-12 DIODE
D106 8-719-970-83 DIODE
D108 8-719-066-10 DIODE
D111 8-719-062-51 DIODE
D201 8-719-062-51 DIODE
D204 8-719-052-12 DIODE
D205 8-719-052-12 DIODE
D206 8-719-970-83 DIODE
D208 8-719-066-10 DIODE
D211 8-719-062-51 DIODE
D301 8-719-062-51 DIODE
D304 8-719-052-12 DIODE
All manuals and user guides at all-guides.com
NOTE: Les composants identifies per un trame et une
marque sont critiques pour la securite. Ne les
!
remplacer que par une piece portant le numero specifie.
VALUES
47µF 20% 35V
0.1µF 10% 250V
0.22µF 10% 16V
47µF 20% 35V
8P
2P
1SS184
RD5.6ESB2
RD5.6ESB2
1PS226-115
1PS226-115
1SS184
RD5.6ESB2
RD5.6ESB2
RD5.6ESB2
RD5.6ESB2
RD5.6ESB2
1PS226-115
1SS119-25
1SS119-25
RD5.6ESB2
1PS226-115
1PS226-115
1SS376TE-17
1SS376TE-17
HSS82-TJ
1PS181-115
1PS226-115
1PS226-115
1SS376TE-17
1SS376TE-17
HSS82-TJ
1PS181-115
1PS226-115
1PS226-115
1SS376TE-17
— 38 —
REF. NO. PART NO. DESCRIPTION
D305 8-719-052-12 DIODE
D306 8-719-970-83 DIODE
D308 8-719-066-10 DIODE
D311 8-719-062-51 DIODE
FERRITE BEAD
FB002 1-216-295-00 SHORT CHIP
FB003 1-412-911-11 FERRITE
FB004 1-412-911-11 FERRITE
FB005 1-412-911-11 FERRITE
FB006 1-216-295-00 SHORT CHIP
FB007 1-216-295-00 SHORT CHIP
FB008 1-216-295-00 SHORT CHIP
FB009 1-414-231-22 FERRITE
FB102 1-469-965-21 INDUCTOR
FB103 1-469-965-21 INDUCTOR
FB104 1-412-911-11 FERRITE
FB110 1-412-911-11 FERRITE
FB202 1-469-965-21 INDUCTOR
FB203 1-469-965-21 INDUCTOR
FB210 1-412-911-11 FERRITE
FB302 1-469-965-21 INDUCTOR
FB303 1-469-965-21 INDUCTOR
FB310 1-412-911-11 FERRITE
IC
IC001 6-700-496-01 IC
IC002 8-759-824-97 IC
IC003 8-759-681-38 IC
IC004 8-749-019-91 IC
IC005 8-759-058-60 IC
IC006 8-759-491-32 IC
IC007 8-759-640-39 IC
IC008 8-759-680-71 IC
IC009 8-759-640-39 IC
IC011 8-759-592-79 IC
JACK
J001 1-451-524-11 SOCKET, CRT
!
CHIP CONDUCTOR
JR001 1-216-296-00 SHORT CHIP
JR002 1-216-296-00 SHORT CHIP
JR005 1-216-296-00 SHORT CHIP
JR007 1-216-295-00 SHORT CHIP
JR008 1-216-296-00 SHORT CHIP
CPD-E530
A1
VALUES
1SS376TE-17
HSS82-TJ
1PS181-115
1PS226-115
1/8W
0µH
0µH
0µH
1/8W
1/8W
1/8W
0µH
0µH
0µH
0µH
0µH
0µH
0µH
0µH
0µH
0µH
0µH
M61314SP
LM2412T/JL860089
CXD9548MTR
H8D3104
TC7SU04FU(TE85R)
TC74VHCT04AF(EL)
BR24C02F-WE2
MM1470AD
BR24C02F-WE2
BA00AST-V5
1/4W
1/4W
1/4W
1/8W
1/4W
