REF. NO. PART NO. DESCRIPTION
JR009 1-216-296-00 SHORT CHIP
JR010 1-216-296-00 SHORT CHIP
JR011 1-216-296-00 SHORT CHIP
JR012 1-216-296-00 SHORT CHIP
JR013 1-216-296-00 SHORT CHIP
JR014 1-216-296-00 SHORT CHIP
JR015 1-216-295-00 SHORT CHIP
JR016 1-216-296-00 SHORT CHIP
JR017 1-216-296-00 SHORT CHIP
JR019 1-216-296-00 SHORT CHIP
JR020 1-216-296-00 SHORT CHIP
JR021 1-216-296-00 SHORT CHIP
JR022 1-216-295-00 SHORT CHIP
JR023 1-216-295-00 SHORT CHIP
JR024 1-216-296-00 SHORT CHIP
JR025 1-216-296-00 SHORT CHIP
JR026 1-216-295-00 SHORT CHIP
JR027 1-216-296-00 SHORT CHIP
JR028 1-216-296-00 SHORT CHIP
JR029 1-216-295-00 SHORT CHIP
JR030 1-216-296-00 SHORT CHIP
COIL
L001 1-412-537-31 INDUCTOR
L002 1-412-549-31 INDUCTOR
L003 1-412-537-31 INDUCTOR
L004 1-412-529-11 INDUCTOR
L005 1-412-537-31 INDUCTOR
L006 1-412-537-31 INDUCTOR
L007 1-412-537-31 INDUCTOR
PIN
* PIN301 4-042-408-01 PIN, COATING LEAD
TRANSISTOR
Q001 8-729-025-28 TRANSISTOR
Q002 8-729-025-28 TRANSISTOR
Q004 8-729-025-28 TRANSISTOR
Q005 8-729-025-28 TRANSISTOR
Q101 8-729-120-28 TRANSISTOR
Q201 8-729-120-28 TRANSISTOR
Q301 8-729-120-28 TRANSISTOR
All manuals and user guides at all-guides.com
VALUES
1/4W
1/4W
1/4W
1/4W
1/4W
1/4W
1/8W
1/4W
1/4W
1/4W
1/4W
1/4W
1/8W
1/8W
1/4W
1/4W
1/8W
1/4W
1/4W
1/8W
1/4W
100µH
1MH
100µH
22µH
100µH
100µH
100µH
2SK1828
2SK1828
2SK1828
2SK1828
2SC1623-L5L6
2SC1623-L5L6
2SC1623-L5L6
— 39 —
REF. NO. PART NO. DESCRIPTION
RESISTOR
R001 1-216-679-11 METAL CHIP
R002 1-216-679-11 METAL CHIP
R003 1-216-025-00 METAL CHIP
R006 1-260-316-51 CARBON
R007 1-216-025-00 METAL CHIP
R008 1-216-025-00 METAL CHIP
R010 1-216-025-00 METAL CHIP
R011 1-216-057-00 METAL CHIP
R012 1-216-057-00 METAL CHIP
R013 1-216-025-00 METAL CHIP
R014 1-260-316-51 CARBON
R015 1-216-057-00 METAL CHIP
R016 1-216-057-00 METAL CHIP
R017 1-216-025-00 METAL CHIP
R018 1-216-025-00 METAL CHIP
R019 1-216-673-11 METAL CHIP
R020 1-216-025-00 METAL CHIP
R021 1-216-025-00 METAL CHIP
R022 1-216-295-00 SHORT CHIP
R023 1-216-049-00 METAL CHIP
R024 1-216-667-11 METAL CHIP
R025 1-216-667-11 METAL CHIP
R027 1-216-017-00 METAL CHIP
R028 1-216-017-00 METAL CHIP
R030 1-216-295-00 SHORT CHIP
R031 1-216-679-11 METAL CHIP
R032 1-260-316-51 CARBON
R033 1-216-651-11 METAL CHIP
R034 1-216-055-00 METAL CHIP
R038 1-216-017-00 METAL CHIP
R039 1-216-017-00 METAL CHIP
R040 1-216-667-11 METAL CHIP
R041 1-216-675-11 METAL CHIP
R043 1-216-295-00 SHORT CHIP
R044 1-216-295-00 SHORT CHIP
R046 1-216-295-00 SHORT CHIP
R047 1-216-295-00 SHORT CHIP
R048 1-216-691-11 METAL CHIP
R049 1-216-691-11 METAL CHIP
R051 1-218-776-11 METAL CHIP
R052 1-259-884-11 CARBON
R053 1-216-627-11 METAL CHIP
CPD-E530
A1
VALUES
15K 0.50% 1/10W
15K 0.50% 1/10W
100 5% 1/10W
100 5% 1/2W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
2.2K 5% 1/10W
2.2K 5% 1/10W
100 5% 1/10W
100 5% 1/2W
2.2K 5% 1/10W
2.2K 5% 1/10W
100 5% 1/10W
100 5% 1/10W
8.2K 0.50% 1/10W
100 5% 1/10W
100 5% 1/10W
1/8W
1K 5% 1/10W
4.7K 0.50% 1/10W
4.7K 0.50% 1/10W
47 5% 1/10W
47 5% 1/10W
1/8W
15K 0.50% 1/10W
100 5% 1/2W
1K 0.50% 1/10W
1.8K 5% 1/10W
47 5% 1/10W
47 5% 1/10W
4.7K 0.50% 1/10W
10K 0.50% 1/10W
1/8W
1/8W
1/8W
1/8W
47K 0.50% 1/10W
47K 0.50% 1/10W
1M 0.50% 1/10W
4.7M 5% 1/4W
100 0.50% 1/10W
