Sony Trinitron CPD-E530 Serviceanleitung Seite 43

NOTE: The components identified by shading
and mark are critical for safety. Replace only
!
with part number specified.
REF. NO. PART NO. DESCRIPTION
C921 1-163-038-91 CERAMIC CHIP
C923 1-126-959-11 ELECT
C925 1-137-372-11 MYLAR
C926 1-106-220-00 MYLAR
C927 1-102-228-00 CERAMIC
C929 1-126-794-11 ELECT
C930 1-136-169-00 FILM
C932 1-164-004-11 CERAMIC CHIP
C933 1-126-786-11 ELECT
C935 1-163-021-91 CERAMIC CHIP
C936 1-163-009-91 CERAMIC CHIP
C937 1-126-796-11 ELECT
C938 1-126-935-11 ELECT
CONNECTOR
CN501 1-793-239-11 PIN, CONNECTOR (PC BOARD)
* CN601 1-580-689-11 PIN, CONNECTOR (PC BOARD)
* CN602 1-691-960-11 PIN, CONNECTOR (PC BOARD)
!
CN604 1-770-724-11 CONNECTOR, BOARD TO BOARD 9P
CN701 1-764-333-11 PIN, CONNECTOR(PCB)(V TYPE)10P
CN904 1-695-915-11 TAB (CONTACT)
CN1101 1-508-879-11 BASE POST
CN1102 1-774-628-11 CONNECTOR, BOARD TO BOARD 17P
CN1103 1-564-511-11 PLUG, CONNECTOR
DIODE
D401 8-719-979-61 DIODE
D405 8-719-109-85 DIODE
D406 8-719-050-84 DIODE
D501 8-719-110-47 DIODE
D502 8-719-054-71 DIODE
D503 8-719-110-47 DIODE
D504 8-719-066-36 DIODE
D505 8-719-052-86 DIODE
D506 8-719-062-89 DIODE
D509 8-719-404-50 DIODE
D510 8-719-082-50 DIODE
D512 8-719-911-19 DIODE
D516 8-719-052-90 DIODE
D517 8-719-082-50 DIODE
D518 8-719-050-84 DIODE
D519 8-719-069-54 DIODE
D520 8-719-911-19 DIODE
D521 8-719-911-19 DIODE
All manuals and user guides at all-guides.com
NOTE: Les composants identifies per un trame et une
marque sont critiques pour la securite. Ne les
!
remplacer que par une piece portant le numero specifie.
VALUES
0.1µF 25V
0.47µF 20% 50V
0.022µF 5% 50V
0.1µF 10% 100V
470pF 10% 500V
4.7µF 20% 50V
0.22µF 5% 50V
0.1µF 10% 25V
47µF 20% 16V
0.01µF 10% 50V
0.001µF 10% 50V
22µF 20% 50V
470µF 20% 16V
6P
4P
4P
8P
EGP10GPKG23
RD5.1ESB2
RB441Q-40T-77
RD18ESB
D5SC4M-F
RD18ESB
FMQ-G5GS
D2L40-TA
HZS5B2-TE
MA111-TX
11DF2N-TA2B2
1SS119-25
D1NL40-TA2
11DF2N-TA2B2
RB441Q-40T-77
UDZSTE-175.1B
1SS119-25
1SS119-25
— 43 —
REF. NO. PART NO. DESCRIPTION
D610 8-719-510-53 DIODE
D613 8-719-304-63 DIODE
D631 8-719-063-73 DIODE
D632 8-719-059-23 DIODE
D633 8-719-069-63 DIODE
D634 8-719-063-73 DIODE
D635 8-719-110-67 DIODE
D641 8-719-069-63 DIODE
D643 8-719-404-50 DIODE
D644 8-719-404-50 DIODE
D650 8-719-064-49 DIODE
D651 8-719-063-74 DIODE
D652 8-719-052-91 DIODE
D680 8-719-510-41 DIODE
D690 8-719-911-19 DIODE
D692 8-719-911-19 DIODE
D694 8-719-911-19 DIODE
D697 8-719-404-50 DIODE
D701 8-719-911-19 DIODE
D702 8-719-911-19 DIODE
D703 8-719-911-19 DIODE
D705 8-719-404-50 DIODE
D706 8-719-069-54 DIODE
D901 8-719-404-50 DIODE
D906 8-719-083-63 DIODE
D907 8-719-052-86 DIODE
D909 8-719-110-47 DIODE
D910 8-719-028-72 DIODE
D911 8-719-018-82 DIODE
D912 8-719-110-42 DIODE
D914 8-719-970-83 DIODE
D917 8-719-069-60 DIODE
D918 8-719-404-50 DIODE
D919 8-719-069-54 DIODE
D920 8-719-977-28 DIODE
D921 8-719-911-19 DIODE
D922 8-719-404-50 DIODE
D923 8-719-404-50 DIODE
FUSE
F601 1-576-233-11 FUSE
!
CPD-E530
D
VALUES
D4SB60L
RM11C
D1NL20U-TR
P6KE200AG23
ERB38-06V1
D1NL20U-TR
RD27ESB2
ERB38-06V1
MA111-TX
MA111-TX
D4SBL40
D1NL20U-TR2
D4SBS4-F
D10SC9M
1SS119-25
1SS119-25
1SS119-25
MA111-TX
1SS119-25
1SS119-25
1SS119-25
MA111-TX
UDZSTE-175.1B
MA111-TX
UDZSTE-1713B
D2L40-TA
RD18ESB
RGP02-17EL-6433
RGP02-20EL-6394
RD15ESB3
HSS82-TJ
UDZSTE-179.1B
MA111-TX
UDZSTE-175.1B
DTZ10B
1SS119-25
MA111-TX
MA111-TX
6.3A 250V
