GB
CHILD'S WEIGHT EXCEEDS 9 KG.
Firstly you must install the car seat base into your vehicle using
the vehicle seat belt or ISOFIX points. See section 'Installing the
base - using the vehicle seat belt' or section 'Installing the
base - using the ISOFIX points'.
You must also ensure that the harness and headrest is set
correctly for your child, to do this see sections 'Headrest and
Safety Harness Adjustment' and 'Harness Tension and Adjust
ment'.
INSTALLING THE CAR SEAT ONTO THE BASE
Place the car seat onto the car seat base facing in the direction of
travel and press the car seat down until you hear a "click" (12).
The car seat can be set in any of its 4 recline positions, to recline
the car seat see section "RECLINING YOUR CAR SEAT".
To remove the car seat from the base, simultaneously press the
car seat release button (Y) while lifting the car seat up out of the
base (13, 14).
INSTALLING YOUR CHILD IN THE CAR SEAT
Firstly open the buckle by pressing the red button in the centre of
the buckle (26). Then sit your child in the car seat, passing their
arms through the shoulder straps.
Bring the harness connectors together and insert into the buckle
until you hear a "click" (27).
Tighten the harness by pulling on the harness adjustment strap
(28), once tight make sure that there is no more than a fingers
width between the harness and your child.
The child's head should sit directly in the middle of the headrest
and the sides of the headrest should sit just above the child's
shoulders, and the shoulder straps should be level with or above
your child's shoulders (25).
If this is not the case please refer to section 'Headrest and Safety
Harness Adjustment'.
