Last Error 310 facilitates troubleshooting and error diagnosis
with the shown error code.
The error message can be acknowledged via the control unit
buttons and digital input STO.
Key Meaning
F00 00 No fault has occurred.
F05 00 Overcurrent; mains unit overloaded, check mains connection and filter.
07 Overcurrent, slow triggering by software.
F07 00 DC link voltage too high, check deceleration ramps and connected
brake resistor.
01 DC link voltage too low, check mains voltage.
F12 05 Fault message of 5-second monitoring. Shut-down paths S1IND and
S7IND were not actuated at the same time, but with an offset of more
than 5 seconds. Check addressing of shut-down paths or control of
protection provision.
06/19
Error messages
Output current
DC link voltage
Safety function STO
