To unregister a channel:
1. Enter registration mode.
Channel 1 LED flashes red/green, or the first unregistered
channel flashes red.
2. If a system device (timer etc) is to be unregistered, enter system
EN
channel registration mode.
The power LED flashes according to the pattern long blink, short
pause, long blink and channel 1 LED flashes red/green.
3. Use buttons < or > to move the pointer (LED flashes red) to the
selected channel (flashes green if registered) to unregister.
4. Press the < and > buttons simultaneously for about 5 seconds
until the LED for the selected channel starts flashing red.
3.5 Unregister all channels
Note
The controller must be unregistered in the interface as
well.
Go to menu Main menu > Preferences > Link and
unregister.
When one or more channels are inaccurately registered, it is possible
to remove all registrations at the same time.
To cancel all channel registrations:
1. Enter registration mode. Channel 1 LED flashes red/green, or
the first unregistered channel flashes red.
2. Press the < and > buttons simultaneously for about 10 seconds
until the LEDs for all channels except one turn off. The one
remaining flashes red.
3.6 Room bypass
To reach the bypass settings, the controller must be registered to the
interface.
1. In the interface, go to the Room bypass menu, Main menu >
System settings > Room bypass.
2. Select a controller.
3. Select up to a maximum of two rooms.
4. Press the Confirm button to save and exit the menu.

3.7 Communications protocol

The system is based on a bus communications protocol (requires the
thermostats unique ID to be registered to the controller), utilising
daisy chain, direct or star topology connections. This allows serial
and parallel connections, makes wiring and connection of
thermostats and system devices much easier than connecting one
thermostat per connection terminal.
The wide array of connection possibilities presented with this
communications protocol can be combined in any way best suited for
the current system.

3.8 Other functions

See full manual for more information about Autobalancing of
actuators (eliminating the need of manual balancing,on by default),
Heat pump integration, Cooling, Comfort/ECO settings, KNX module,
Room check, and Supply check etc.
10 | Uponor Smatrix Base PRO | Quick guide
