User Manual
Not attending to the regulations and safety instructions might cause fatal accidents,
injuries, and damages to persons and property.
4

Monting and Operating

4.1

Preparation

1. Check the scope of delivery for completeness and integrity.
2. Compare the specifications of product, power supply and peripherals.
3. Insert the spiral-shaped metal holder into the corresponding opening of
4. Soak the viscose cleaning sponge with clean water and drain it well
5. The soldering tip is mounted into the shaft and fixed by a safety socket
6. Change the soldering tip only at the cooled down soldering iron.
7. In order to do so, unscrew the union nut at the soldering iron and push
Now the soldering tip is exposed and you can pull it off carefully.
7. The screw connections should be inspected regularly regarding their
. 8. Fix the soldering stand to the right side of the soldering station by plug
The soldering iron may not be operated without the soldering tip in
any case!
4.2

Connection

•
Now the soldering station is ready to use.
4.3

Adjusting the Temperature

1. Only switch on the soldering station when having adapted to room tem
In case of transporting the the soldering station from cold to warm rooms
the sudden change of temperature may lead generating condensation water
causing negative effects r damages to the electronics of the device.
2. Switch on the soldering station by turning the mains switch into the I-
By using the rotary switch, the soldering temperature can be adjusted
steplessly from 150 to 450 °C, also during use at every time.
In case of defects the soldering station has to be switched off imme-
diately, disconnected from mains and checked regarding possible
causes of the error.
.
14
These must be identical.
the soldering iron stand.
before replacing it in the sponge tray.
to the soldering iron.
off the s afety socket.
tight fitting and, if required, be tightened accordingly.
ging in.
Connect the mains plug of the soldering station with the 220 - 240 V AC
/ 50 Hz mains socket, while the mains switch is turned off to the 0-sta-
tus.
perature.
status. The soldering station is heating up now.
