5.4 Step 4
20 O P E R A T I N G I N S T R U C T I O N S | DLS40
Tighten the coupler screws
Figure 5: Tighten the screws
Coaxiality
• Follow the coupling instructions
NOTE
m
X
Figure 6: Coaxiality
X
X
