Product overview

1 Dust hose
2 Hose connector
3 Extension tube
4
Power cord
5
Main handle
6
Rotation lock
7 Guide rail
8 Sanding pad latch
9 Triangular sanding pad
10 Round sanding pad
11 Sanding base plate
12 Hinge locking lever
13 Speed level display
14
Speed level setting keys
15
On / Off switch
16
Auxiliary Handle

Preparing the tool

Warning! Switch of and unplug the
tool before any preparation, disassem-
bly, exchange, and maintenance work.
1 UNFOLDING THE TOOL
Unfold the tool at the hinge. Slide the
hinge locking
as shown. Press down the hinge locking
lever until it snaps into place.
1 EXTENSION TUBE
To connect or disconnect the extension
tube 3, loosen the hose connector
the tool.
104 EN
lever 12 towards the hinge
2 on

Intended use

The tool is intended for dry sanding of drywalls,
ceilings and walls, as well as removing paint
residues, adhesives and loose plaster. The tool is
not intended for commercial use or for removing
material containing toxic materials e.g. Asbestos.
Any other use or modification to the tool is consid-
ered as improper use and could cause consider-
able dangers.
2 FOLDING THE TOOL
Pull the hinge locking
tool for transport and storage.
2
Set the appropriate length by pushing in
or pulling out the extension tube 3. Re-
fasten the hose connector 2.
Caution! Do not extend beyond the
"Max" marking.
lever 12 to fold the
