AL-KO EasyMow 1200 Betriebsanleitung Seite 32

en
Language selection
[ Select language ]
English
Deutsch
The corresponding language only needs to be
selected here during the initial start-up.
1 Use the [arrow keys] (3-3) to select the requi-
red language.
2 Confirm with the [multifunction key] (3-5).
After confirming, the LCD display (3-1)
shows [Enter registration PIN].
PIN code
Entering the factory-set PIN code
The factory-set PIN code only needs to be entered
during the initial start-up. The factory-set PIN code
is [0000].
[ Registration ]
Enter PIN
****
1 Use the corresponding [arrow keys] (3-3) to
select the corresponding digits and confirm
each one with the [multifunction key] (3-6).
2 Enter the next 3 required digits in the same
way.
Following this, the LCD display (3-1)
shows the [Change PIN] dialogue box.
Changing the PIN code
1 Enter a new PIN and repeat.
After this, the LCD display (3-1) shows
the [Date dialogue box].
Setting or changing the date
Enter the date and time correctly, because further
programming depends on the date and time.
32
Confirm
[ Enter the date
DD.MM.YYYY
13.06.2013
1 Use the corresponding [arrow keys] (3-3) to
select the corresponding digits and confirm
each one with the [multifunction key] (3-5).
After confirming, the LCD display (3-1)
shows [Time dialogue box].
When entering the year (YYYY), it is only
necessary to enter the last two digits be-
cause the first two 20XX are preset.
Setting or changing the time
[ Enter time ]
24 hour format
7:00
Abort
1 Use the corresponding [arrow keys] (3-3) to
select the corresponding digits and confirm
each one with the [multifunction key] (3-5).
Following this, the LCD display (3-1)
shows the [Uncalibrated] status window.
Calibration
For calibration, set up the robotic lawn mower ac-
cordingly (12-3).
1 The automatic calibration procedure starts
when the [START key] (3-4) is pressed.
The [Drive starting] warning flashes on
the LCD display (3-1).
CAUTION!
The drive starts when the [START key]
is pressed.
Do not reach into rotating parts.
Calibration procedure
The robotic lawn mower first moves straight over
the boundary cable in order to gauge the signal
strength, and then into the base station. The bat-
tery of the robotic lawn mower is charged.
Startup
]
Confirm
Confirm
Robotic lawn mower
