Optional Accessories; Technical Data - LiftMaster LM3800W Installationsanleitung

33

Optional Accessories

Always use LiftMaster accessories.
External products can cause malfunctions.
1. TX4UNIF
2. TX4EVS
3. TX4UNI/S
4. 128EV
5. 747EV
6. 78EV
7. FLA-1LED
8. 772E
9. 100034
10. 100041
11. 829EV
12. 485EU
13. 827EV
14. 041A9264
15. 841EU
34

Technical Data

Input Voltage
Max. Torque
Nominal Torque
Power
Standby Power
Motor Type
Noise level
Travel Rate
Safety Personal
Electronic
Electrical
Limit Device
Limit Adjustment
Start Circuit
Max. door height
Max. door width
Max. door area
Max. door weight
Hanging Weight
Receiver Memory Registers
Operating Frequency
4-channel universal remote control
4-channel remote control
4-channel universal remote control
Wireless Wall Control 2-Channel
Keypad
Wired multi-functional wall control
Flashing light
Photocells
Key switch (flush mount)
Key switch (surface mount)
Garage Door Monitor
Battery Backup
MyQ Remote LED Light:
Cable Tension Monitor
Automatic Door Lock
230-240 VAC, 50 Hz
36 Nm - AC + Battery 29 Nm - AC only
10 Nm
150 W
2.6 W
DC gearmotor permanent lubrication
57dB
21 rpm (down), 36 rpm (up)
Push button and automatic stop in down direction. Push button and automatic stop in up direction.
Automatic force learning.
Transformer overload protector and low voltage push button wiring.
Optical RPM / Position detector.
Electronic limit adjustment.
Low voltage push button circuit.
3 m
5.5 m
16.5 m²
130 kg
11 kg
64
433 / 868 MHz, 2.4 GHz
19 / en
