1.3.5 Serial Ports

CN2
CN1
COM 1 COM 2
(Teal/Turquoise)
1.3.6 Game/MIDI Port and Audio Jacks
Line-out
Line-in
Mic-in
9 1 9 1
10 2
10
2
Front
audio
(J5)
Mic-in (Pink)
Line-in
Line-out
(Lime) (Light Blue)
Quick Setup Guide
COM 1
COM 2
Serial Port
Serial Port
Onboard Game/MIDI / Audio
Game/MIDI Port
Audio Jacks
Line-out
Line-in
Mic-in
Front Audio (J5)
1 Mic+
2 Ground
3 N. C.
4 AuD_Vcc (Avcc)
5 AuD_R-Out
6 N. C.
7 N. C.
8 Key
9 AuD_L_Out
1 0 N. C.
1
11
