Overview of the control panel:
Button
Turn the machine on and off.
A beep sounds each time the "ON/OFF" button is pressed.
Select a drink. The selection is backlit.
Select the steam function in order to foam the milk to make a milk-
based drink manually. The selection is backlit.
Press before drink selection to increase or reduce the coffee strength,
by modifying the amount of ground coffee. You have 3 possible
choices, from weak to strong. The selection is backlit with 1 to 3
beans.
Press before drink selection to increase or reduce the volume of the
drink, by modifying the volume of water used. You have 3 possible
choices, from a small to large drink. The selection is backlit with 1 to 3
drops.
Start or stop the current drink.
This warning icon appears on the control panel when there is a
problem linked to the machine's operation. For example, when there is
no water, coffee beans or maintenance is required.
Press before drink selection to make double the amount. The selection
is backlit with 2 cups.
Allows access to the maintenance functions: rinsing, cleaning and
descaling. The relevant maintenance function is backlit.
Accesses the "Favourite" menu and your saved favourites / After
a drink is made, it allows you to save a favourite. You can save 2
favourites: A and B. The selected favourite A or B is backlit.
36
OVERVIEW
Description / General Functions

TOUCHSCREEN INTERFACE

Our interface and its buttons light up intuitively way to facilitate the use of the machine and
to guide you.
Light status
Unlit button
Press the pulsing light (dimly lit with
long flashes)
Press the flashing light
Lit button/bright light
INTUITIVE WARNING LIGHTS
Your machine is equipped with intelligent technology to make daily life easier. The machine
automatically detects and controls the levels of coffee beans, water and ground coffee.
When these containers must be filled or emptied, a warning light will notify you.
If maintenance is required, the "warning" LED
one or more of the three light bars will be lit:
Intuitive warning light Action to be performed
Water container (U) The water tank is almost empty, it must be refilled. See 7
– REFILLING THE WATER TANK fig 1 to 7.
Coffee bean container (V) The coffee bean container is almost empty, it must be refilled.
See 8
– REFILLING THE COFFEE BEAN CONTAINER, fig 1 to 8.
Coffee grounds collector The collector is filled with coffee grounds, it must be emptied.
(W) See 9
– EMPTY THE COFFEE GROUNDS COLLECTOR, fig 1 to 5.
GETTING STARTED
INSTALLING THE APPLIANCE
Switching on and preparing the machine
Danger:
Connect the appliance to a grounded 230 V socket. Otherwise, you expose
yourself to fatal injuries due to the presence of electricity!
Respect the safety information in the "Safety information" leaflet.
Priming the machine allows the water circuits to be filled, so that the machine can operate.
Preheating and automatic rinsing will take place.
Meaning
The corresponding function is not selected/is
not accessible.
An action with the selected function is in
progress
An action is in progress
The function is selected
appears on the touchscreen interface and
