4.Protections, Troubleshooting & Maintenance

4.1Protections

PV Over Current/Power
PV Short Circuit
PV Reverse Polarity
Night Reverse Charging
BATT1 and BATT2 Reverse
Polarity
BATT1 Over Voltage
BATT1 Over Discharge
BATT1 Overheating
BATT1Low
Temperature(Lithium
Battery)
Controller Overheating
TVSHigh Voltage
Transients

4.2 Troubleshooting

Faults phenomenon
Charging LED indicator off during
daytime when sunshine falls on
PV modules properly
Wire connection is correct,the
controller is not working.
red on solid
Red fast flashing
①System alarm a voltage fault
②System alarm an over
when using Lead-acid battery
discharge fault when the BATT1
③System alarm an over-voltage
is 12V but set as 24V
fault when BATT1 set as 12V and
BATT2 set as 24V
