axing EOC 1-31 Schnellstartanleitung Seite 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
EU Declaration of Conformity:
Hereby AXING AG declares that the marked products comply with the valid
guidelines.
EOC 2-31: Hereby AXING AG declares that the device is in compliance
with Directive 2014/53/EU. The full text of the EU declaration
of conformity is available at the following internet address:
https://axing.com/en/downloads/ce/
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
State of the art 2020-09-18
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Typ EOC 1-31
Frequency range
Connectors (G.hn | TV)
Frequency range transmission
Frequency range TV bypass
Max. attn. in coaxial network
Transmission level in coaxial
network
EoC
Standard ITU-T G.9960/G.9961 G.hn over Coax
Net data rate (PHY)
Max. number of devices in EoC
network
Interfaces
Ethernet connectors (LAN)
Ethernet standards IEEE 802.3u 100BaseT Fast Ethernet
IEEE 802.3ab 1000BaseT Gigabit Ethernet
WiFi standard -
WiFi encryption -
Common
Operation voltage
Power consumption 4 W
Operating temperature range
(acc. to EN 60065)
Dimensions (W × H × D) appr. 130 x 95 x 32 mm
External accessories
Plug-in power supply unit 100...240 V~/50...60Hz
12 V=/0,5 A
Commission regulation (EU) 2019/1782
External plug-in power supply
EOC 1-31
Manufacturer's name or trademark Channel Well Technology Co Ltd
commercial registration number and 222 Sec 2 Nankan Rd, Lujhu Township Taoyuan
address Hsien, 33855 Taiwan | 84573516
Model identifier 2AAR006F EU
Input voltage 100...240 V
Input AC frequency 50...60 Hz
Output voltage 12,0 V
Output current 0,5 A
Output power 6,0 W
Average active efficiency
Load condition 1 – 100 % ± 2 % 80,4 %
Load condition 2 – 75 % ± 2 % 80,7 %
Load condition 3 – 50 % ± 2 % 80,8 %
Load condition 4 – 25 % ± 2 % 79,1 %
Efficiency at low load (10 %) 72,2 %
No-load power consumption 0,05 W
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
EOC 2-31
5...1218 MHz
2 × F-female
5...65 MHz
258...1218 MHz
77 dB
113 dBµV ± 1dB
EOC 1-31 | EOC 2-31
720 Mbps
16
premium-line
2 × RJ 45
Ethernet over Coax
MIMO 2x2
Peer to Peer
IEEE 802.11b/g/n/a/ac
WEP, WPA/WPA2, WPA/
WPA2 m. PSK
Quick start guide
12 VDC
8 W
0°C...40°C
100...240 V~/50...60Hz
12 V=/1 A
EOC 2-31
2AAJ012F EU
100...240 V
50...60 Hz
12,0 V
1,0 A
12,0 W
82,5 %
83,7 %
84,0 %
83,4 %
75,7 %
0,04 W
