Protalker 1116
10.6.5 Other functions
By use of the optional PC programming cable and the downloadable programming software, you
can assign other functions to both function keys :
• Alarm : sending an alerting tone to other PT-1116 users
• Battery power check : check the battery status
• Whisper : activate an extra microphone amplifier so you can whisper in the microphone
if required. The receiving PMR radio will understand you better. In normal conditions,
whisper mode should be disabled.
• VOX : enable/disable VOX : only when using a VOX headset with VOX switch.
Not all headsets support VOX-mode !!
• Compander : enable/disable voice compressing for extra clear modulation (noise
reduction). It is recommenced that all users enable the compander at the same time for
optimal result.
11 External speaker/microphone connection
You can connect an optional speaker/microphone (shoulder microphone, ear tube, PC
programming cable,...) via the side panel connectors.

Insert the speaker/microphone plug into the speaker/microphone
jack of the PT-1116.
The diagram in Annex B shows how the speaker/microphone is connected.
12 VOX
By use of the optional PC programming cable and the downloadable programming software you
can enable VOX in the radio.
When using a VOX-headset make sure to follow the steps below :
– Enable VOX by use of the PC software
– Switch off the PT-1116
– Set the headset switch to VOX
– Insert the speaker/microphone plug of the headset into the speaker/microphone jack of
the PT-1116.
– Switch back on the PT-1116.

13 Technical specifications

Please refer to Annex C for the technical specifications.
4

14 Warranty

14.1 Warranty period
The devices have a 24-month warranty period. The warranty period starts on the day the new
unit is purchased. There is no warranty on standard or rechargeable batteries.
Consumables or defects causing a negligible effect on operation or value of the equipment are
not covered. The warranty has to be proven by presentation of the original or copy of the
purchase receipt, on which the date of purchase and the unit-model are indicated.
14.2 Warranty exclusions
Damage or defects caused by incorrect treatment or operation and damage resulting from use
of non-original parts or accessories are not covered by the warranty.
The warranty does not cover damage caused by outside factors, such as lightning, water and fire,
nor any damage caused during transportation. No warranty can be claimed if the serial number
on the units has been changed, removed or rendered illegible. Any warranty claims will be invalid
if the unit has been repaired, altered or modified by the buyer
7
