CONDTROL NEO G200 Bedienungsanleitung Seite 4

CROSS
EN
LINE LASER
9
2
1
5
6
7
1 - Laser lines exit window
2 - Control panel
3 - Battery cover
4 - 5/8'' mounting thread
5 - Compensator lock
6 - Mounting screw hole
7 - Mounting clip
8 - Belt mount hole
9 - Power jack
6
CONDTROL NEO G200
user manual
8
4 3
CROSS
EN
LINE LASER
Control panel
3
1
1 Turn on/off laser lines in unlocked mode
2 Turn on/off:
- Pulse mode
- Laser lines in locked mode
3 Battery charge level indication
4 Locked pendulum indication
5 Pulse mode indication
