MACHINE COMPONENTS

1
2
3
4
7
8
9
MACHINE COMPONENTS
1 Recovery tank lid
2 Recovery tank
3 Solution tank fill-port
4 Scrub head
5 Solution tank
6 Squeegee assembly
7 Squeegee foot pad
8 Caster
9 Tires
10 Control handle

- OPERATION -

5
6
11 Emergency shut-off button
12 Squeegee vacuum hose
13 Recovery tank drain hose
14 Control handle start bail
15 Control panel
16 Key switch
17 Battery charger
18 Speed control knob
19 Forward/Reverse lever
10
18
11
12
13
14
19
15
16
17
