10/12 VT-MSPA | Ventilverstärker

Zuordnung: Schalterstellung/Ventiltyp

Typ VT-MSPA1
Schalterstellung Ventiltyp (1 Magnet)
0-0 kein Ventil
0-1 4WRA6...-2X
0-2 4WRA10...-2X
0-3 4WRZ...-7X
0-4 3DREP6...-2X
0-5 4WRPH6...-2X (SO855)
0-6 DBEP6...-1X
0-7 DBET-6X...G24...
0-8 DBET-6X...G24-8...
0-9 DBETX-1X...G24-25...
1-0 DBETX-1X...G24-8...
1-1 (Z)DBE6-2X...
1-2 DBEM10...-7X...G24...
1-3 DBEM10...-7X...G24-8...
1-4 DBEM20...-7X...G24...
1-5 DBEM20...-7X...G24-8...
1-6 DBEM30...-7X...G24...
1-7 DBEM30...-7X...G24-8...
1-8 (Z)DRE6...-1X...
1-9 ZDRE10...-2X...G24...
2-0 ZDRE10...-2X...G24-8...
2-1 DRE...10...-6X...G24...
2-2 DRE...10...-6X...G24-8...
2-3 DRE...20...-6X...G24...
2-4 DRE...20...-6X...G24-8...
2-5 DRE...30...-6X...G24...
2-6 DRE.30...-6X...G24-8...
2-7 3DRE...-7X...G24...
2-8 3DRE...-7X...G24-8...
2-9 3FREX6...-1X...G24-25...
3-0 3FREX10...-1X...G24-25...
3-1 3DREP6...-2X... (SO674)
3-2
Z3DRE10..-1X...G24...
3-3 DBE6X-1X...G24-25...
3-4
DBE6X-1X...G24-8...
3-5 DRE6X-1X---G24-8...
3-6
DBET-1X..HG24-8...
3-7 Pump Control 1 (0,7 A)
EP2 (A7VO)
3-8 Pump Control 2 (0,6 A)
ED72 (A10VSO/31)
ER72 (A10VSO/31)
3-9 Pump Control 3 (0,6 A)
EP2 (A10VSO/52, 53)
EK2 (A10VSO/52, 53)
L4 (A15VSO...)
E2 (A15VSO...)
EP2,6(A6VM)
Verfügbar ab Serie 21
1)
Verfügbar ab Serie 22
2)
Bosch Rexroth AG, RD 30232, Ausgabe: 2020-09
1)
1)
1)
1)
1)
Schalterstellung Ventiltyp (1 Magnet)
4-0 DBE10Z-1X..G24-8..
4-1
DRE10Z-1X...G24-8...
4-2 (Z)3DRE6...-2X/...G24...
4-3 (Z)3DRE6...-2X/...G24-8...
9-6 Universal (0,8 A)
9-7 Universal (1,6 A)
9-8 Universal (2,5 A)
1)
1)
2)
2)
