Thrustmaster TH8A Add-on Shifter Benutzerhandbuch Seite 202

‫ﺗﺭﻛﻳﺏ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
1.
‫ﺃﺩﺭ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ ﺑﺎﺗﺟﺎﻩ‬ :( B ) ‫( ﻋﻠﻰ ﺍﻟﻌﺻﺎ ﺍﻟﺧﺎﺻﺔ ﺑﻪ‬ A ) ‫ﻟﺗﺛﺑﻳﺕ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
.‫ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬
2.
.‫ﺃﺩﺭ ﺍﻟﻣﻘﺑﺽ ﻓﻲ ﻋﻛﺱ ﺍﺗﺟﺎﻩ ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬ :‫ﻟﻔﻙ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
‫ﺇﺣﻛﺎﻡ ﺍﻟﺭﺑﻁ‬ ‫ﻓﻙ‬
‫ﻝ ﺍﻟﺳﺭﻋﺔ‬ ‫ﺗﺭﻛﻳﺏ ﺫﺭﺍﻉ ﺗﺑﺩﻳ‬
:‫ﺗﻡ ﺗﺣﺳﻳﻥ ﻋﻣﻠﻳﺔ ﺍﻟﺗﺭﻛﻳﺏ ﻟﺗﻧﺎﺳﺏ ﺃﻱ ﻧﻭﻉ ﻣﻥ ﺃﻧﻭﺍﻉ ﺍﻟﺩﻋﺎﻣﺎﺕ‬
.( ) ‫ﻣﻡ، ﻋﻥ ﻁﺭﻳﻖ ﺟﻬﺎﺯ ﺍﻟﺗﺛﺑﻳﺕ‬ 55 ‫ﺇﻟﻰ‬ 1 ‫ﺫﺍﺕ ﺳﻣﻙ ﻳﺗﺭﺍﻭﺡ ﻣﻥ‬ ‫ﺍﻟﻣﻧﺎﺿﺩ ﺃﻭ ﺍﻟﻁﺎﻭﻻﺕ ﺃﻭ ﺍﻷﺭﻓﻑ‬ -
H
‫ﻛﺭﺍﺳﻲ ﺍﻟﺳﺑﺎﻕ‬
.(‫، ﻋﻥ ﻁﺭﻳﻖ "ﺍﻷﺳﻧﺎﻥ ﺍﻟﻠﻭﻟﺑﻳﺔ" ﺍﻟﻣﺿﻣﻧﺔ )ﻳﻣﻛﻥ ﻓﺻﻝ ﺟﻬﺎﺯ ﺍﻟﺗﺛﺑﻳﺕ‬ -
‫ﻣﻧﺿﺩﺓ ﺃﻭ ﻁﺎﻭﻟﺔ‬ ‫ﺗﺭﻛﻳﺏ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ ﻋﻠﻰ‬
.‫ﺿﻊ ﺍﻟﺟﺯء ﺍﻟﻧﺎﺗﺊ ﻣﻥ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ ﻋﻠﻰ ﻣﻧﺿﺩﺓ ﺃﻭ ﺳﻁﺢ ﻣﺳﺗ ﻭ ٍ ﺁﺧﺭ‬ 1 .
.‫ﺃﺩﺭ ﻋﺟﻠﺔ ﺍﻟﺗﺛﺑﻳﺕ ﻓﻲ ﻋﻛﺱ ﺍﺗﺟﺎﻩ ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬ :‫ﻹﺣﻛﺎﻡ ﺍﻟﺭﺑﻁ‬ 2 .
.‫ﺃﺩﺭ ﻋﺟﻠﺔ ﺍﻟﺗﺛﺑﻳﺕ ﻓﻲ ﺍﺗﺟﺎﻩ ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬ :‫ﻟﻠﻔﻙ‬ 3 .
‫ﺇﺣﻛﺎﻡ ﺍﻟﺭﺑﻁ‬ ‫ﻓﻙ‬
