17. Tightly screw the front screw (2) into the adapter using the stipulated torque (use the T40 Torx adapter).
Torque: M8 screws: 25 Nm ± 2 Nm
18. Tightly screw the screw (3) through the adapter into the nut (4) using the stipulated torque (use the T40
Torx adapter and the SW13 spanner for this).
Torque: M8 screws: 25 Nm ± 2 Nm
19. Now move the seat as far forward as possible.
20. Tightly screw the four screws (5, 6) at the rear using the stipulated torque (use the T40 Torx adapter).
Torque: M8 screws: 25 Nm ± 2 Nm
M
1
21. Slide the storage compartment into the seat console.
22. Tightly screw the storage compartment (1) using the four original screws (2) (cross-head screwdriver).
Danger:
If the torque is not set correctly, the screws will work loose whilst you are driving.
In this case, the safety concept can no longer be ensured and the vehicle may no longer be used.
The screws must be tightened using the stipulated torque.
RECARO Automotive Seating
2
1 Storage compartment
2 Cross-head screws
K0259
