RECARO C 6000 IVECO Stralis Einbauanleitung Seite 32

B
4. Move the steering wheel as far forward as possible.
5. Move the backrest into the vertical position and the seat into the rearmost and highest position.
C
1
6. Loosen the two screws (1) in the floor at the front and remove the screws and nuts (size 6 hexagon
socket adapter & SW13 spanner).
7. Now move the seat as far forward as possible.
8. Loosen and remove the four screws (2) in the floor at the rear of the seat
(size 6 hexagon socket adapter).
RECARO Automotive Seating
Steering wheel adjustment - front
Standard seat adjustment - rear, top
2
1 Front screws
2 Rear screws
K0240
Page 9 of 23
