3.5 Fitting the hose/cable harness to the RECARO seat

Important note:
The hose/cable harness must be fitted to the RECARO seat when it is outside the vehicle.
If a hose/cable harness has already been fitted to the seat you should remove it and dispose of it.
Do this by placing the seat on its backrest in order to prevent the panels or the handles from being
damaged.
.
Warning:
During the installation, ensure that the electrical and pneumatic connections do not become
contaminated or damaged, in order to guarantee a secure contact.
G
1
1. Fit the hose/cable harness (1) from the adapter kit to the RECARO seat.
2. Connect up the pneumatic (2) and the electrical (3) connectors.
Warning:
You must ensure that the hose/cable harness does not get caught up, damaged or become
subjected to any stress or over-tensioning during the remainder of the installation, as the correct
functioning of the controls cannot be guaranteed otherwise.
RECARO Automotive Seating
2
3
1 hose/cable harness
2 Pneumatic connector
3 Electrical connector
K0236
Page 13 of 23
