2. Package Contents and Technical Specifications
Handheld Vacuum Cleaner
1
2
3
4
1. Extension Wand/Crevice Tool Release Button
2. Automatic Emptying Dust Intake
3. Dust Container Cover Release Button
4. Clear Dust Container
5. Power Indicator
6. Air Outlet Cover
7. Air Outlet Cover Release Button
8. Handheld Vacuum Cleaner Power Button
9. Handle
10. Dust Container Release Button
Advanced Wet/Dry Cleaning Cloth and Advanced Wet/Dry Reservoir
1
2
3
4
8
EN
5
6
7
8
9
10
11
12
13
18
17
14
16
19
11. Handheld Vacuum Cleaner Battery
Release Button
12. Handheld Vacuum Cleaner Battery
13. Handheld Vacuum Cleaner Charging Contacts
14. Dust Container Filter Net
15. Air Outlet Filter
16. Extension Wand
17. Crevice Tool
18. Fabric Brush Release Button
19. Fabric Brush
1. Advanced Wet/Dry Cleaning Cloth
2. Advanced Wet/Dry Reservoir
3. Water Inlet
4. Velcro
15
