Special functions

Calibration check Checks calibration of
the targets fitted on the car (with 8 targets only).
Single value Shows only one angle of
the selected axle at a time.
Maximum steering angle Activates
and deactivates the maximum steering angle
procedure.
2WS steering angle Recalls the steer-
ing angle procedure for vehicles with 2-wheel
steering.
4WS steering angle Recalls the steer-
ing angle procedure for vehicles with 4-wheel
steering.
Adjustment with car lifted Starts the
procedure for adjusting an axle with the car lifted.
End of adjustment with car lifted Ends
the procedure for adjusting an axle with the car
lifted, lower the vehicle.
Chassis input degrees Manual com-
pilation of the chassis height record with data
in degrees.
Chassis input mm Manual compilation of
the chassis height record with data in millimetres.

Menu management

Open menu Opens the menu containing
the additional icons for which there is no room
in the icon bar.
Recall other icons Displays the second
set of icons in the sub-menu.
Close menu Closes the menu containing
the additional icons.
Operator's manual EXACT LINEAR

RUNOUT Compensation

Push Mode ROC Recalls the push
compensation procedure that does not require
vehicle lifting.
ROC skip Continues vehicle align-
ment operations, skipping the compensation
procedure.
ROC recall Recalls the compensation
values saved previously.
Databank
Car markets Selection of the distribu-
tion markets of the databank vehicles.
Commercial description of vehicle De-
scription of the vehicle with the commercial name.
Manufacturer's description of vehicle
Description of the vehicle with the name given
by the manufacturer for univocal identification
of the alignment reference data.
Databank selection Selection of the
databank archive from which the vehicles will
be selected.
Main databank Sets the main archive
as the databank for use.
User databank Sets the secondary ar-
chive entered by the user as the databank for use.
Both databanks Sets the combina-
tion of the main and secondary archives as the
databank for use.

Printout and job record

Print Prints the data.
Save and print Saves the current
job in the jobs archive and prints the data.
