6.3 Mounting the Hanging Rope
Step 1. Put the end of the rope through the hole.
Step 2. Put another end of the rope through the first one and then tighten it.
7. Operating Guide
1) Insert the two batteries properly to the direction, and then replace the cover.
2) Open the clip as shown in Figure 5.
3) Let the patient's finger put into the rubber cushions of the clip (make sure the finger is in the right
position), and then clip the finger.
4) Press the switch button once on front panel.
5) Do not shake the finger and keep the patient at ease during the process. Meanwhile, human body is
not recommended in movement status.
6) Get the information directly from screen display.
7) The device could change display direction according to the handing direction.
Fingernails and the luminescent tube should be on the same side.
8. Cleaning, Transportation and Storage
Please change the batteries when the low-voltage displayed on the screen.
•
• Please clean the surface of the device before using. Wipe the device with medical alcohol first, and
then let it dry in air or clean it by dry clean fabric.
Using the medical alcohol to disinfect the product after use, prevent from cross infection for next
•
time use.
• Please take out the batteries if the oximeter is not in use for a long time.
• The best storage environment of the device is -40ºC to 60ºC ambient temperature and not higher
than 95% relative humidity.
High-pressure sterilization cannot be used on the device.
Do not immerse the device in liquid.
It is recommended that the device should be kept in a dry environment. Humidity may reduce the
useful life of the device, or even damage it.

9. Troubleshooting

Trouble
The SpO2 and Pulse Rate can not
be displayed normally
The SpO2 and Pulse Rate are not
displayed stably
The device can not be turned on
The display is off suddenly
Figure 5 Finger Position
Possible Reason
1. The finger is not properly
positioned
2. The patient's SpO2 is too low
to be detected.
1. The finger is not placed inside
deep enough.
2. The finger is shaking or the
patient is moving.
1. The batteries are drained or
almost drained.
2. The batteries are not inserted
properly.
3. The malfunction of the device
1. The device will power off
automatically when it gets no
signal within 5 seconds.
2. The battery is almost drained
Solution
1. Place the finger properly and
try again.
2. Try again; Go to a hospital for
a diagnosis if you are sure the
device works all right.
1. Place the finger properly and
try again.
2. Let the patient keep calm
1.Change batteries
2. Reinstall batteries.
3. Please contact the local
service center.
1. Normal.
2.Change batteries
EN
