Service information
Maintenance of a medical device is wholly the responsibility of the owner of that device. Failure to maintain a
device in accordance with the instructions may invalidate the device's warranty. Furthermore, failure to maintain a
device may compromise the clinical condition or safety of users and/or their caregivers. Do not perform service and
maintenance while the user is in the product.
Contact local dealer for assistance, if needed, in setting up, using or maintenance of the device.
1st Day
EN
• Read the User Guide carefully before use and
store it in a safe place for future reference
• Store the enclosed tools on/at the product
Daily
• Use a dry cloth to clean the product
• Visual inspection. Repair or replace any
damaged or worn-out parts
• Ensure that all fasteners are in place and fitted
correctly
• Check all fittings and buckles for signs of worn
out parts
• Be aware of any MAX mark indications before
adjustment
Weekly
• Check that all wheels are moving freely and
that all wheel locks/brakes are easily activated
• Wipe off any residue and dirt from the product
using a cloth with warm water and a mild
detergent/soap and dry before use
• Disinfect the product. please check the
disinfection section in this User Guide for more
information
• Tire pressure
Monthly
• All nuts and bolts on this product must be
checked and tightened to avoid unnecessary
failures
• Oil the swing-away parts. We recommend you
use a professional lubricant system
Annually
• Inspect the frame for cracks or signs for worn-
out parts and carry out annual service. Never
use a product which appears to be substandard
or faulty
WHEELS
Wheel axles: The axles should be kept free of dirt.
Clean as frequently as necessary.
Ball bearings:
maintenance.
Handrims: If a handrim should be damaged in such
a way that it could lead to hand injury, it should be
replaced.
22" tires: Check the air pressure (recommended: 55
PSI/3,8 bar/380 kPa) and tread at a regular basis. For
instance by your local bicycle engineer.
12½" tires: Check the air pressure (recommended: 35
PSI/2,5 bar/240 kPa) and tread at a regular basis. For
instance by your local bicycle engineer.
Brakes
The function of the brakes is dependent upon tire
pressure. Caked on dirt can have a negative effect on
the brake mechanism. The brakes should be checked
at least once a month.
The ball bearings require
For safety routinely check to make sure the distance
between the wheel and the wheel lock block is: 8-10
mm. The brakes should not be activated when the
frame is stored as this could result in a flat spot in the
solid inner of the tyre. If drum brakes are mounted,
the cables have to be adjusted, to ensure the brakes
are working properly. Make sure the wheels can not be
turned around when the brakes are activated.
Warewashing machine
This product can be washed at 60° using a mild
detergent for 10 minutes in a washing machine
designed for medical devices. Use the machine's
drying function to dry the product.
Disinfection
The product without accessories and cushion can be
disinfected with a 70% disinfectant IPA solution. It is
recommended to wipe off any residue and dirt from
the product, using a cloth with warm water and a mild
detergent/soap without chlorine and let it dry before
disinfection.
Service interval
A detailed inspection of the product must be made
every 12 months (every 6 months for heavy users),
every time the product is reissued for use and
after long term storage (more than 4 months). The
inspection should be carried out by a technically
competent person who has been trained in the use of
the product.
Service Check List:
Check and adjust the following functions as per their
intended use. Repair or replace any damaged or worn-
out parts. Please check the:
• Seat plane adjustment. The seat plane
is adjustable and stays in position after
adjustment.
• If a seat adapter is mounted, check that the
red handle for locking works and that the safety
lock "clicks into position when placing a seat
into the adapter
• Wheels are moving freely and that all wheel
locks/brakes are easily activated. Adjust if
required
no
• Quick release wheels are removable/
replaceable
• Anti-tips can be fixed in working and resting
position
• Tire pressure
• Spoke guards is without cracks and secured
to the wheel with the clips mounted on each
guard
• The Pushbrace can be folded over the frame
• Before storage: Always deactivate wheel locks/
brakes
• Nuts and bolts on the product are tightened
• Oil the swing-away parts
• Product for cracks or signs for worn-out parts
• All labels on the product are intact
