ENGLISH
These tests consist of filling the water tank in order to check
tightness and to ensure correct operating of the device. Once
the test has been carried out, the tank is emptied and dried,
but there is a slight probability that water could remain inside
it.

2. PARTS AND COMPONENTS

Fig.1
1.Fill opening
2.Water tank handle
3.Water tank
4.Unit base
5.Cord slot
6.Temperature control
7.Soleplate
8.Handle
9.Steam trigger
10.Lock button
11.Shell
12.Heatproof stand
13.Control panel
Temperature dial
Fig. 2.
1.170 ºC-225 ºC (Maximum)
2.140 ºC-210 ºC
3.100 ºC-160 ºC
4.70 ºC-120 ºC (Minimum)
Buttons and indicators
Fig. 3.
1.ON / OFF indicator
2.Descaling indicator
3.Refill indicator
4.Power switch
22 TOTAL IRON 8500 IMPLODE / 9000 TURBO-BOOST
