Play mode
SD
The screen displays a list of recorded video clips (in .avi format) and
captured images (in .jpg format). Use the (16) and (17) buttons to
select the required video clip or image. Press the "OK" (10) button to
play a file. Press the "OK" (10) button again to pause a file. Use the
(16) REW and (17) FWD buttons to rewind a file. To speed up/slow
down rewinding press the respective button.
Press the "mode" button (15) to exit Play mode.

MOTION DETECTION

Start the device and the video recorder, select option "Motion
detection".
Press the "OK" (10) button, select option "Yes".
Turn the switch (13) to the "rec" position.
The record icon "AUTO" is displayed in the top left-hand corner of the
screen.
Press the "OK" (10) button to switch the video recorder to stand-by
mode. As soon as a moving object appears in the field of view,
recording starts automatically ("rec" icon displays in the top left-hand
corner of the screen).
Note: as illuminance level decreases, the distance at which a moving
object can be detected, goes down.
After the object is out of the device's field of view recording continues
for 10 seconds and then stops automatically ("rec" icon goes out).
Recorder returns to stand-by mode again.
Turn the switch (13) to the "play" position and press "mode" (15) to
proceed to the menu.
Note: it is advised that you install the
using Motion detection.
8
Press the "ON" (2) button to start
the device.
Press and hold the "on/off"
button (12) for 4-5 sec to start the
video recorder. The blue LED
indicator (14) on the right of the
"on/off" button (12) will light up.
Turn the switch (13) to the "play"
position.
Recon 750R o n a tripod when
6

SD MEMORY CARD

Video clips and images captured are saved to the SD memory card
only. The device does not have internal memory. Maximum capacity
of a memory card should not exceed 4Gb.
Doing so may damage the memory card and the device, and corrupt
data stored on the card.
Max. recording time depending on the card capacity and video clip
resolution:
Capacity of memory card
512Mb
1Gb
2Gb
4Gb
After recording you can remove the memory card and view or process
recorded data using some peripheral equipment (PC, lap-top etc.). Press
the memory card to release it from the slot. Pull out the memory card.
Please format the memory card in
the device before use. Follow
instructions set forth in option
"Format" of menu "Set up".
Open the cover of the memory
card slot. Insert the card in the slot
as shown in the picture and push it
in. You can hear a click when the
card locks into place.
Close the cover of the memory
card slot. Ensure that the cover is
properly closed.
Do not remove the memory
card during an operation when
the card is being accessed.
640x480 (VGA) 320x240 (QVGA)
28 min 102 min
55 min 200 min
111 min 400 min
222 min 800 min
