3 Installaion MT iQ Solar
For installaion please
remove the posiive cable
between the solar control-
ler and your batery from
the posiive terminal.
Pass this cable through
the opening of the current
sensor exactly as shown
in the picture on the right.
Now reconnect cable again
with the pole terminal.
When using
Solar controllers simply
pass all other plus cables
through the current sensor too. This allows monitoring and
displaying the overall performance of all installed solar
systems.
All plus cabling from the solar controllers
! !
need to be fed through the sensor. For safety
reasons pull-out the fuse on your solar con-
troller and put it back again ater assembly.
BÜTTNER ELEKTRONIK – MT iQ Solar
+
muliple
Important!
Pro
Pro
