This universal remote control (4 in 1) is compatible with the majority of television sets, DVD
players and video recorders, amplifiers and Hi-Fi and Home Cinema systems, as well as
digital boxes such as satellite or cable receivers, DVBT receivers (Digital Video Broadcast
Terrestrial), ADSL decoders, and so on. This remote control was programmed in the factory,
so that you can use it to control most of the sets of the THOMSON group's make. For this
reason, we recommend that prior to attempting to programme the remote control, you try it
out by means of one of the methods described in this user manual. However, first of all, you
must install 2 batteries (AAA) in the remote control.
Please keep this guide along with the code list (provided separately), so that you can
subsequently programme your remote control for use with other sets.
:
1 Mode keys Select the device to control (TV, DVD, ...).
2 : On/Standby or Standby only, depending on the equipment being used.
3 Learn : Used for the learning codes procedure i(key copying) (see page 3)
and turning backlight On/Off.
4 Macro : Macro selection (see page 4).
5 : Teletext On.
: Teletext hold.
: Teletext Mix.
: Teletext Off.
6 Setup : Allows you to program your remote before the first use. It also allows you
to access to secondary functions of certain A/V appliances (Shift). Press and
release the "Setup" key followed by the function key you want.
7 i : Displays information of the selected appliance.
8 P<P : Previous channel.
9 Wide : Change the size of the image (4/3, 16/9, etc...).
10 Coloured keys : Can be used to select categories when teletext is activated, and specific
functions depending on the make.
11 / / / : Allow you to navigate the menus horizontally and verticaly.
OK : Confirms a selection.
12 Exit : Turn off the menu of the selected product.
13 Menu : Turns on the menu of the selected product.
14 CH /CH : Channel Up and Channel Down buttons.
15 Guide : Electronic Program Guide.
16 (Mute) : Switches the selected appliance sound off.
17 Vol+/Vol- : Increases (+) or decreases (-) the volume of the selected device.
18 (Play) : Play a DVD disc (DVD, ...).
(FF) : Fast forward (DVD, ...).
(RW) : Goes backward (DVD, ...).
(Pause) : Suspends play and stops on an image.
(Stop) : Stop the disc (DVD, ...).
(Record) : To record, press the RECORD key twice.
19 Numeric keys 0-9 : These keys have the same functions as those of your original remote and are
also used to enter the codes for different products. Selection of a macro (M1, M2, M3)
20 -/-- : Access to channel > 9 and Radio selection depending of the device.
21 AV : For selecting an external source (SCART, HDMI, ...).
Testing the remote control before
you programme it
1. Turn on the product you want to control.
2. Press the Mode key that corresponds to the type
of product you want to control: TV: television set,
DVD: DVD player, , SAT/STB: satellite or cable
receiver, AMP: AUDIO equipment or any other
equipment.
3. Direct the remote control towards your equipment
and try to switch it off by simply pressing the key G.
If the device does not turn off, you must program the
remote control using one of the methods A, B, C or
D described hereafter.
Note 1: Except for the TV key, the DVD, SAT/
STB and AMP mode keys can be programmed
to control a device other than that indicated on the
key. It is therefore possible, for example, to allocate
SAT mode to the DVD key. You must enter the code
corresponding to the manufacturer and the device by
using one of the methods indicated in this manual.
However, method D (automatic search for a code)
will greatly simplify the task for you. In this case it
is only necessary to enter a code from the list that
corresponds to the type of device, for example: 0603
for a Thomson satellite receiver) and then to run the
automatic search procedure. The remote control will
then test all the codes automatically until it finds those
that control the receiver.
Note 2: To control 2 devices of the same type and the
same brand (2 Thomson VCRs, 2 Thomson satellite
receivers, ...) ensure first that these two devices are not
set to react to the same sub code, they will require one
sub code for one and a different sub code for the other
(i.e., codes A and B with Thomson devices). Once you
have checked this, successively program 2 separate
mode keys using method D.
manuals search engine
The keys
Programming
the remote control
Method A – Fast programming
with 1-digit subcode
Before you start programming, you must find the
subcode of the set to be controlled. Entering a subcode
lets the remote control test a predefined list of codes.
Refer to the list provided with these instructions, page
I of the subcodes.
1.Switch on the set you want to control.
2.Hold down the SETUP key until the indicator lamp
blinks and then remains lit (the indicator light
remains on for a few seconds to give you the time to
proceed with the following steps. The indicator lamp
flashes to signal that this time is almost up, and then
goes off).
3.Press the key that corresponds to the type of equipment
you want to control: TV: television set, DVD: DVD
player, , SAT/STB: satellite receiver, cable, DVBT,
ADSL, AMP: AUDIO equipment and any other
appliance.
4.While the indicator is lit, type in the subcode
(example: 1 for THOMSON).
5.Direct the remote control towards the set and try to
switch it off by pressing the key G.
6.If the set you want to control switches off, press OK
to memorise the code.
7.Should the set not switch off, press key G repeatedly,
until the set switches off. Between two key presses,
leave enough time for the indicator lamp to light up
again (about 1 second). Proceeding this way will
enable you to see whether the set responds or not.
8.Immediately upon the switching-off of the set to be
controlled, press OK to store the code.
